MULTICOMP PRO 7030089 LED Lamp
The 703-0089 is a 3mm round LED lamp with an orange epoxy resin encapsulation, utilizing a GaAsP/GaP chip for bright illumination. It offers a power dissipation of 78mW, operates at a reverse voltage of 5V, and has a low reverse leakage current of 100pA. Designed for reliable performance, it functions across temperatures from -25°C to 85°C. This orange LED delivers a luminous intensity of 20 to 50 millicandelas, with a forward voltage of approximately 2.6V, and a viewing angle of 35 degrees, making it ideal for industrial indicator and signaling applications.
MULTICOMP PRO 7030089 LED Lamp Specifications:
- Package Size: 3mm diameter round LED
- Luminous Intensity: 20-50 millicandelas at 20mA
- Forward Voltage: 2.6V at 20mA
- Peak Wavelength: 642 nm
- Dominant Wavelength: 629 nm
- Operating Temperature Range: -25°C to +85°C
- Storage Temperature Range: -40°C to +100°C
- Power Dissipation: 78 mW
- Reverse Voltage: 5 V
- Reverse Leakage Current: 100 pA
- Viewing Angle: 35 degrees
- Peak Wavelength Spectrum Linewidth: 35 nm
- Soldering Temperature (1.6mm from body): Dip Soldering 260°C for 5 sec, Hand Soldering 350°C for 3 sec
Buy the Buy Multicomp LED Lamp Part Number 7030089 Online
Purchase the Multicomp orange LED lamp part number 7030089 online today to enhance your industrial signaling projects. This 3mm round LED features a GaAsP/GaP chip, delivering 20-50 millicandelas of brightness with a forward voltage of 2.6V. It operates reliably between -25°C to 85°C, with a power dissipation of 78mW and a viewing angle of 35 degrees. Easy to solder and RoHS compliant, it is ideal for indicator lights, displays, and control panels, ensuring consistent performance in demanding environments.
Order your Multicomp Series7030089 orange LED lamp today and give your projects the dependable, high-brightness illumination they deserve.
Frequently Asked Questions
Where can I buy MULTICOMP PRO 7030089?
You can click on the BUY or RFQ button to purchase 7030089 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part 7030089?
You can download the 7030089 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of 7030089?
MULTICOMP PRO
