MULTICOMP PRO 8317985 Temperature Humidity Module
The MULTICOMP PRO 83-17985 is a sophisticated temperature and humidity module designed for a wide range of applications. It combines a capacitive humidity sensor, a high-precision temperature measurement device, and a microcontroller for accurate and reliable readings. The module offers ultra-low power consumption, a wide operating temperature range (-40°C to 80°C), and a long transmission distance (up to 20 meters). It's ideal for HVAC systems, data loggers, medical devices, and other applications requiring precise humidity and temperature monitoring and control. Each sensor undergoes factory calibration for exceptional accuracy.
MULTICOMP PRO 8317985 Temperature Humidity Module Specifications:
- Operating Temperature Range: -40 to 80 °C
- Humidity Range: 0 to 99.99 %RH
- Humidity Resolution: 0.1 %RH
- Humidity Accuracy: ±2 %RH at 25°C
- Humidity Repeatability: ±0.3 %RH
- Temperature Resolution: 0.1 °C
- Temperature Accuracy: ±0.5 to ±1 °C
- Temperature Repeatability: ±0.2 °C
- Response Time: <5 seconds (humidity), <10 seconds (temperature)
- Power Supply Voltage: 3.3 to 5.5 V (recommended 5V)
- Power Consumption (Dormancy): 10-15 μA
- Power Consumption (Measuring): 500 μA
- Power Consumption (Average): 300 μA
- Interface: Single-bus (3-lead)
- Dimensions: Refer to datasheet image
