MULTICOMP-PRO G749A Twin Cable
This twin cable features PVC insulation with figure '8' construction, made of plain annealed copper conductors suitable for various electrical applications. It includes different color options such as grey, white, and black, with a conductor size of 0.34 mm² (7/0.25 mm). The cables are designed for low voltage and current-rated applications, with a voltage rating of 60V and a maximum DC resistance of 55Q/km at 20°C. Overall diameter of approximately 1.4 x 2.8mm, with a sheath tensile strength of 28 N/mm and elongation of 2100%. The cables meet BS standards for insulated cables and cords.
MULTICOMP-PRO G749A Twin Cable Specifications:
- Conductors: 0.34 mm² (7/0.25 mm)
- Construction: 2x conductors laid parallel with polarity rib
- Temperature Rating: -15°C to +70°C
- Overall Diameter: 1.4mm x 2.8mm
- Nominal Wall Thickness: 0.32mm
- Insulation Material: PVC
- Insulation Thickness: Min 0.55mm, Nominal 0.65mm
- Spark Voltage: 3,000V AC
- Sheath Elongation: 2100%
- Sheath Tensile Strength: 28 N/mm²
- Inner Conductor Resistance: 55Q/km at 20°C
- Voltage Rating: 60V rms
- Current Rating: 1A
- Reel Length: 100m
- Color Options: Grey, White, Black
- Part Numbers: 2X463 GRY, 2X463 WHI, 2X463 BLK
- Standards: BS 6360, BS 7655
Buy the Buy Premier Farell Twin Copper Cable Part Number G749A Online
Secure your electrical installations with our high-quality twin copper cables, perfect for low-voltage applications. Featuring PVC insulation and a figure '8' design, these cables provide reliable conductivity. Available in grey, white, and black, with a conductor size of 0.34 mm² and rated at 60V. Each reel offers 100 meters of durable wiring with excellent tensile strength and elongation properties. Easily order online today to ensure your projects benefit from this dependable, compliant cable suitable for various electrical needs.
Order your Premier Farell Twin Copper Cable G749A today and enhance your electrical projects with reliable, high-quality twin insulated wiring.
Frequently Asked Questions
Where can I buy MULTICOMP-PRO G749A?
You can click on the BUY or RFQ button to purchase G749A from an authorized MULTICOMP-PRO distributor.
How do I troubleshoot issues or seek technical support for part G749A?
You can download the G749A datasheet or visit the MULTICOMP-PRO website for support.
Who is the manufacturer of G749A?
MULTICOMP-PRO
