MULTICOMP PRO GBPC2508W Bridge Rectifier
The GBPC2508W is a high-reliability bridge rectifier designed for various electrical applications. It features plastic housing with an integrally molded heatsink for efficient heat dissipation, surge overload ratings from 300 to 400A, and solderable terminals compliant with MIL-STD-202, method 208. With a typical reverse current under 0.2uA and high-temperature soldering capability at 260°C for 10 seconds, it provides isolated voltage from case to lead over 2,500V. Suitable for single-phase, half-wave configurations, it offers ratings up to 800V and 35A, making it ideal for rectification in power circuits.
MULTICOMP PRO GBPC2508W Bridge Rectifier Specifications:
- Maximum Recurrent Peak Reverse Voltage VRRM: 1,000V
- Maximum RMS Voltage Vrms: 700V
- Maximum DC Blocking Voltage Voc: 1,000V
- Maximum Average Forward Rectified Current: 35A
- Peak Forward Surge Current: 400A
- Maximum Instantaneous Forward Current: 17.5A
- Forward Voltage Drop: 1.4V at 12.5A
- Maximum DC Reverse Current Ir: 5mA
- Thermal Resistance (Junction to Case): 1.5°C/W
- Operating Temperature Range: -50°C to +150°C
- Dimensions: 0.762 inches (19.1 mm) diameter, hole for #10 screw, 0.432 inches (11 mm) large flange
- Material: Plastic with integrally molded heatsink
- Surge Overload Ratings: 300-400A
- Solder Terminals: MIL-STD-202 method 208
- Isolation Voltage: over 2,500V from case to lead
- Lead Length: 0.375 inches (9.5mm)
- Maximum Reverse Voltage: up to 1,000V
Buy the Multicomp Series GBPC2508W Bridge Rectifier: 800V 35A Power Module
Order the Multicomp GBPC2508W online today and ensure your power circuits are equipped with a reliable, high-capacity bridge rectifier. With ratings up to 1,000V and 35A, this module features an integrated heatsink for excellent heat dissipation, surge overload capability of 300-400A, and solderable MIL-STD-202 terminals. Its high-temperature soldering compatibility at 260°C makes it suitable for demanding industrial environments. Perfect for single-phase power conversion, the GBPC2508W guarantees safety with over 2,500V isolation from case to lead, supporting efficient and safe electrical operation.
Buy Multicomp GBPC2508W now and experience unmatched reliability and high-performance power rectification for your electrical applications.
Frequently Asked Questions
Where can I buy MULTICOMP PRO GBPC2508W?
You can click on the BUY or RFQ button to purchase GBPC2508W from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part GBPC2508W?
You can download the GBPC2508W datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of GBPC2508W?
MULTICOMP PRO
