MULTICOMP PRO HC49S1030507030ATF Surface-mount Crystal
The HC49S-10-30-50-70-30-ATF is a compact surface-mount crystal measuring 10.9 x 4.65 mm, designed for applications where board height is limited. It features 30 and 50 ppm frequency stability, a superior resistance weld metal case, and a low profile. The crystal operates in the fundamental vibration mode, with a maximum equivalent series resistance of 50Ω, a maximum shunt capacitance of 5pF, and a minimum insulation resistance of 500MΩ at 100V DC. Suitable for clock and timing applications, as well as use in industrial and communication systems.
MULTICOMP PRO HC49S1030507030ATF Surface-mount Crystal Specifications:
- Dimensions: Length 10.9 mm, Width 4.65 mm, Height 4 mm
- Frequency Range: 10 to 30 MHz
- Vibration Mode: Fundamental (AT), 3rd Overtone (AT)
- Frequency Tolerance at 25°C: +20, +30, or +50 ppm
- Temperature Stability: +30 ppm or +50 ppm
- Operating Temperature Range: -10°C to +60°C (option: -20°C to +70°C)
- Storage Temperature Range: -20°C to +70°C (option: -30°C to +80°C)
- Load Capacitance: 8 pF to 32 pF or series
- Equivalent Series Resistance: Max 50Ω
- Shunt Capacitance: 5 pF maximum
- Drive Level: 200 μW maximum (<5 MHz), 100 μW maximum (>5 MHz)
- Insulation Resistance: 500 MΩ minimum at 100 V DC
- Aging: +5 ppm per year
Buy the Buy multicomp crystal Part Number HC49S1030507030ATF Online
Order the multicomp crystal HC49S1030507030ATF online today and enhance your electronic devices with its compact design, high stability, and excellent resistance. Ideal for industrial, communication, and microcontroller applications, this low-profile crystal offers precise frequency control with 30 and 50 ppm stability, suitable operating temperature range, and durable construction. Get fast delivery and ensure your projects have accurate timing and reliable performance by purchasing this essential component directly from trusted online distributors.
Buy multicomp crystal HC49S1030507030ATF now and experience reliable performance and precise timing in your electronic designs.
Frequently Asked Questions
Where can I buy MULTICOMP PRO HC49S1030507030ATF?
You can click on the BUY or RFQ button to purchase HC49S1030507030ATF from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part HC49S1030507030ATF?
You can download the HC49S1030507030ATF datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of HC49S1030507030ATF?
MULTICOMP PRO
