MULTICOMP PRO HC49S1630507030ATF Surface-mount crystal
The HC49S-16-30-50-70-30-ATF is a compact surface-mount crystal measuring 10.9 x 4.65 mm. It features a low-profile design, ideal for space-constrained applications such as industrial, communication, and networking systems. The crystal operates in the fundamental vibration mode with frequency ranges from 10 MHz to 30 MHz, offering high stability with +20, +30 or +50 ppm tolerance at 25°C. It has a maximum ESR of 40Ω, shunt capacitance of 5pF, and insulation resistance of 500MΩ at 100VDC, providing reliable clock signals and precise timing for microcontrollers and embedded systems.
MULTICOMP PRO HC49S1630507030ATF Surface-mount crystal Specifications:
- Nominal Frequency Range: 10 to 30 MHz
- Vibration Mode: Fundamental (AT)
- Frequency Tolerance at 25°C: +20, +30 or +50 ppm (Options: +10, +15 ppm)
- Temperature Stability: +30 ppm or +50 ppm
- Operating Temperature Range: -10°C to +60°C
- Storage Temperature Range: -20°C to +70°C
- Load Capacitance: 8 pF to 32 pF or series
- Equivalent Series Resistance: Max 40Ω
- Shunt Capacitance: 5pF maximum ($18 MHz)
- Drive Level: 200μW maximum (<5 MHz)
- Insulation Resistance: 500MΩ minimum at 100V DC
- Dimensions: 10.9 x 4.65 mm
- Maximum Resistance Weld Metal Case
Buy the Multicomp Series Crystals: HC49S16-30-50-70-30-ATF
Order the Multicomp HC49S crystal today and benefit from a compact, low-profile design with high frequency stability and reliable operation. Perfect for industrial, communication, and networking applications, this surface-mount crystal measures 10.9 by 4.65 millimeters, making it ideal for space-constrained electronic devices. Featuring a maximum ESR of 40 ohms and shunt capacitance of 5pF, it ensures precise timing signals and robust performance across various operating conditions. Purchase online now for quick delivery and quality assurance.
Buy Multicomp HC49S16-30-50-70-30-ATF now and experience unmatched reliability and performance in space-efficient timing solutions.
Frequently Asked Questions
Where can I buy MULTICOMP PRO HC49S1630507030ATF?
You can click on the BUY or RFQ button to purchase HC49S1630507030ATF from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part HC49S1630507030ATF?
You can download the HC49S1630507030ATF datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of HC49S1630507030ATF?
MULTICOMP PRO
