MULTICOMP PRO HGBJ2516 3 Phase Bridge Rectifier
The HGBJ2516 is a glass passivated three-phase bridge rectifier designed for high reliability and efficiency in power supply applications. It features a positive forward voltage drop, an insulation voltage of 2,500V, and small size with lightweight construction, making it suitable for DC equipment power supplies, PWM converter input rectifiers, and DC motor drives. The device offers a peak repetitive voltage of 1,600V, a maximum average forward current of 25A at 110°C, and a peak surge current of 350A. Its thermal resistance is 0.8°C/W, with a wide operating temperature range from 55°C to +150°C, ensuring stable performance across various environments.
MULTICOMP PRO HGBJ2516 3 Phase Bridge Rectifier Specifications:
- Peak Repetitive Voltage VRRM: 1600V
- Peak Non-Repetitive Reverse Voltage VrsM: 1700V
- Maximum Average Forward Rectified Current Iw: 25A at Tc = 110°C
- Peak Forward Surge Current Irsm: 350A
- Maximum Forward Voltage Drop: 14V at Vr
- Reverse Peak Current Vr = VrrM @ Ts = 25°C: 5 pA
- Vr = Varm @ Ts = 150°C: 3 mA
- Insulation Voltage Viso: 2,500V
- Thermal Resistance (junction to case): 0.8°C/W
- Operating Temperature Range: -55°C to +150°C
- Weight: 10g
- Dimensions: 1.874 inches x 0.689 inches (47.6mm x 17.5mm), small size for compact designs
- Mounting torque recommended: 0.8 N·m
Buy the Buy Multicomp Glass Passivated 3 Phase Bridge Rectifier Part Number HGBJ2516 Online
Purchase the Multicomp Series HGBJ2516 3-phase bridge rectifier online today for high reliability in power supply applications. This efficient rectifier features a high insulation voltage of 2500V, a peak repetitive voltage of 1600V, and a maximum current rating of 25A at 110°C. Its compact size and lightweight design make it ideal for DC equipment, PWM converter input rectifiers, and DC motor drives. Get superior thermal performance with a thermal resistance of 0.8°C/W, ensuring stable operation across temperature ranges from -55°C to +150°C. Buy now and power your projects with confidence.
Order your Multicomp Series HGBJ2516 high-performance 3-phase bridge rectifier today and ensure reliable power conversion for your industrial projects.
