MULTICOMP PRO LD0805GWK Digital LED Display
This green dual digit common cathode LED display measures 20.3mm (0.8 inches) and is designed for bright, reliable digital readouts in various electronic applications. Constructed with GaP dice material, it features a peak wavelength of 568 nm, resulting in vibrant green emission. The display operates within a temperature range of -40°C to +85°C, consuming up to 85 mW power at 20 mA current with a forward voltage of 1.8 to 2.5 V. Its white diffused lens enhances visibility, making it suitable for industrial and commercial digital display solutions, with excellent electrical and optical characteristics for long-term, stable operation.
MULTICOMP PRO LD0805GWK Digital LED Display Specifications:
- Dice Material: GaP
- Peak Wavelength: 568 nm
- Emitted Colour: Green
- Lens Colour: White Diffused
- Surface Ink Colour: Black
- Luminous Intensity: 23 mcd (typical)
- Viewing Angle: 120°
- Forward Voltage: 1.8 - 2.5 V
- Power Dissipation: 85 mW
- Forward Current: 20 mA (recommended)
- Peak Forward Current: 100 mA
- Reverse Voltage: 5 V
- Reverse Current: 10 μA
- Operating Temperature Range: -40°C to +85°C
- Storage Temperature Range: -40°C to +100°C
- Lead Soldering Temperature: 260°C for 5 seconds
Buy the Multicomp Series Digital LED Display: LD0805GWK
Experience the reliability and brightness of the Multicomp Digital LED Display. With a 20.3mm size, green emission at 568 nm, and durable GaP construction, this display is perfect for digital readouts. Designed for a temperature range of -40°C to +85°C, it offers excellent stability and high luminous intensity. Easy to install with standard soldering, it ensures long-lasting performance in various electronic projects. Order now to enhance your digital display systems with this high-quality component, suitable for industrial and commercial use.
Get Multicomp LD0805GWK today—built for bright, reliable digital readouts in industrial and commercial applications.
Frequently Asked Questions
Where can I buy MULTICOMP PRO LD0805GWK?
You can click on the BUY or RFQ button to purchase LD0805GWK from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part LD0805GWK?
You can download the LD0805GWK datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of LD0805GWK?
MULTICOMP PRO
