MULTICOMP PRO MC000030 Wire-to-Board Terminal Block
The MC000030 is a 6-way, 16A wire-to-board terminal block featuring a tin-plated brass terminal, a green polyamide 66 insulating body, and a nickel-plated steel cage clamp with screw connections. It supports screw wire termination and is designed for right-angle through-hole mounting. The terminal block offers a maximum insulation resistance of over 2000 megaohms at 500V DC. It operates within a temperature range of -40°C to 105°C, making it suitable for various electrical applications requiring reliable, high-insulation standards. This component is ideal for industrial and electronic assemblies demanding durable and secure wire connections.
MULTICOMP PRO MC000030 Wire-to-Board Terminal Block Specifications:
- Rating current: 16 amperes, 300 V ac
- Minimum insulation withstand voltage: 2,000 V ac
- Insulation resistance: >2,000 MΩ at 500 V dc
- Operating temperature: -40°C to +105°C
- Wire strip length: 4 to 5 mm
- Wire range: 21 to 26 AWG
- Screw torque: 27 Ib-inch
- Material: Insulating body Polyamide 66 - Green
- Cage clamp: Steel Ni plated
- Terminal: Brass Tin plated
- Screw: Steel Ni plated
- Pitch: 5 mm (0.197 inch)
- Number of poles: 6 (for MC000030)
Buy the Multicomp Series Terminal Block: 6-Way Wire-to-Board Connectors: MC000030
Order the Multicomp MC000030 terminal block online and enjoy effortless installation with a durable, high-insulation design. Perfect for industrial and electronic projects requiring reliable, secure connections with wire range compatibility from 21 to 26 AWG. Its green polyamide body ensures excellent insulation, while the brass terminal offers high durability. Whether for manufacturing or maintenance, buy this 6-way terminal block now to ensure a dependable electrical connection in your assembly. Limited warranty and high customer ratings make it a trusted choice for professionals.
Buy Multicomp MC000030 now and experience unmatched reliability and performance in secure wire connections for industrial electronics.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MC000030?
You can click on the BUY or RFQ button to purchase MC000030 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MC000030?
You can download the MC000030 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MC000030?
MULTICOMP PRO
