MULTICOMP PRO MC000105 Right Angle Terminal Block
The MC000105 is a 3-way, 10A right-angle pluggable terminal block with a green polyamide 66 insulating body, tin-plated phosphor bronze contacts, and a nickel-plated steel screw. It features screw wire connection technology, a minimum insulation withstand voltage of 2000 VAC, and an insulation resistance exceeding 2000 megaohms at 500V. Operating effectively between -40°C and 105°C, this terminal block is designed for reliable and secure electrical connections in various applications. It belongs to the Multicomp Pro line, known for quality, durability, and user satisfaction.
MULTICOMP PRO MC000105 Right Angle Terminal Block Specifications:
- Current Rating: 10 Amperes
- Min. Insulation Withstand Voltage: 2,000V AC
- Insulation Resistance: >2,000 Megaohms at 500V DC
- Operating Temperature: -40°C to +105°C
- Wire Strip Length: 6.5mm
- Wire Range: 16 AWG to 24 AWG
- Screw Torque: 3 Ib-inch
- Material: Insulating Body Polyamide 66 - Green
- Contact Material: Phosphor Bronze Tin Plated
- Cage Clamp: Brass Ni plated
- Screw Material: Steel
- Pitch: 3.81mm (0.15 inch)
- Poles: 2 to 12 (various arrangements)
- Dimensions vary based on pole configuration, e.g., 12 Way: 46.51mm (1.831 inch)
- Certification: RoHS Compliant
Buy the Buy Multicomp Pluggable Terminal Block Part Number MC000105 Online
Order the Multicomp Pluggable Terminal Block MC000105 online today to ensure high-quality, reliable connections for your electrical projects. Featuring a compact right-angle design, it provides a rated current of 10A and withstands voltages up to 2000V AC, making it suitable for diverse applications. Its green polyamide body ensures excellent electrical insulation and durability in harsh environments. With an operating temperature range of -40°C to +105°C, it offers versatility, easy installation, and long-lasting performance—perfect for professional and DIY electrical setups.
Buy Multicomp MC000105 now and experience secure, reliable electrical connections with high current capacity and robust construction.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MC000105?
You can click on the BUY or RFQ button to purchase MC000105 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MC000105?
You can download the MC000105 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MC000105?
MULTICOMP PRO
