MULTICOMP PRO MC000189 Pluggable Terminal Block
The MC000189 is an 8-way, 16A, right-angle pluggable terminal block featuring a green polyamide 66 insulating body, tin-plated phosphor bronze contacts, and a nickel-plated steel screw. It utilizes screw wire connection terminals and offers a minimum insulation withstand voltage of 2000VAC. The terminal block has an insulation resistance greater than 2000 megaohms at 500V, a screw torque of 4.5 lb-inch, and an operating temperature range from -40°C to 105°C. Designed for reliable electrical connections, it is part of Multicomp Pro’s product line, which is rated 4.6 out of 5 stars with a 12-month limited warranty, and 96% of customers would recommend it to a friend.
MULTICOMP PRO MC000189 Pluggable Terminal Block Specifications:
- Current rating: 16 amperes
- Voltage rating: 300 V ac
- Minimum insulation withstand voltage: 2,000 V ac
- Insulation resistance: > 2,000 MΩ at 500 V dc
- Operating temperature: -40°C to +105°C
- Wire strip length: 7mm
- Wire range: 14 to 24 AWG
- Screw torque: 4.5 lb-inch
- Material: Polyamide 66 - Green
- Contact Material: Phosphor Bronze, Tin plated
- Cage Clam: Brass
- Screw: Steel
- Pitch: 5.08 mm (0.2 inch)
- Poles: 8
- Dimensions: 25.4 mm length, 40.64 mm width, 20.32 mm height
Buy the Multicomp Series 8-way Terminal Block: MC000189
Purchase the pluggable terminal block MC000189 online today for robust and safe electrical connections. Featuring an 8-way design, 16A current capacity, and high-quality materials including a green polyamide insulating body and tin-plated contacts, this terminal block withstands temperatures from -40°C to 105°C. Its screw wire connection ensures secure attachment, with a minimum insulation withstand voltage of 2000VAC. Perfect for industrial applications, it combines durability, ease of installation, and excellent performance, making it an essential component for wiring and control systems.
Order your Multicomp Series 8-way terminal block MC000189 today and ensure reliable electrical connections with high quality and safety.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MC000189?
You can click on the BUY or RFQ button to purchase MC000189 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MC000189?
You can download the MC000189 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MC000189?
MULTICOMP PRO
