MULTICOMP PRO MC000201 Terminal Block
The pluggable terminal blocks are RoHS compliant and designed for reliable electrical connections in various industrial applications. They feature a rated current of 12 amperes and a voltage rating of 300V AC, with insulation withstand voltage of 2,000V AC and insulation resistance exceeding 2,000 megaohms at 500V DC. Operating within a temperature range of -40°C to +105°C, these connectors have a pitch of 5.08mm (0.2 inches). The body is made from green polyamide 66, and brass solder pins are tin-plated for durability. Available in multiple configurations, these headers offer flexibility for different circuit needs, including 2 to 12 ways with corresponding pole measurements. Suitable for PCB applications, they ensure secure connections for automation and control systems.
MULTICOMP PRO MC000201 Terminal Block Specifications:
- Rated Current: 12 Amperes
- Voltage Rating: 300V AC
- Min. Insulation Withstand Voltage: 2,000V AC
- Insulation Resistance: > 2,000MQ at 500V DC
- Operating Temperature: -40°C to +105°C
- Pitch: 5.08mm (0.2 Inch)
- Body Material: Polyamide 66 - Green
- Solder Pin Material: Brass, Tin Plated
- Pole Options: 2, 4, 6, 8, 10, 12 Ways
- Dimensions vary with number of poles, starting from 11.76mm for 2 poles up to 62.56mm for 12 poles.
Buy the Multicomp Series 5.08mm Terminal Block: MC000201
Purchase the reliable Multicomp terminal block MC000201 online today. Designed for industrial electrical connections, it features a 5.08mm pitch, current rating of 12 amperes, and a voltage capacity of 300V AC. Its high insulation withstand voltage of 2,000V AC and resistance over 2,000 megaohms ensure safety and durability. Made with robust polyamide and tin-plated brass pins, it offers multiple configurations from 2 to 12 poles, making it ideal for PCB circuit connections. Secure your projects with this high-quality, RoHS compliant connector available online for fast delivery.
Get Multicomp MC000201 today—built for secure connections in industrial automation and control systems.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MC000201?
You can click on the BUY or RFQ button to purchase MC000201 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MC000201?
You can download the MC000201 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MC000201?
MULTICOMP PRO
