MULTICOMP PRO MC002258 Solid State Relay
This high-quality PCB mount solid state relay supports single-phase AC output with a maximum load current of 2A and voltage of 240V AC. Designed for high-density PCB and PLC control applications, it features optoelectronic isolation, a control voltage of 5V or 24V DC, and zero crossing switching for reduced electrical noise. Compliant with RoHS standards, it offers dielectric strength of 2500V AC rms, rear mounting via DIN rail, and a compact design weighing only 4 grams. Suitable for industrial automation requiring reliable, efficient switching.
MULTICOMP PRO MC002258 Solid State Relay Specifications:
- Control Voltage: 5V DC, 24V DC
- Input Circuit Voltage Range: 4-6V DC (5V), 19.2-28.8V DC (24V)
- Maximum Input Current: 25mA
- Load Voltage Range: 24-280V AC
- Maximum Surge Voltage: 600Vpk
- Load Current Range: 0.1-2A
- Maximum Turn-on Time (Zero Crossing): 10ms
- Maximum Turn-off Time: 10ms
- Maximum Surge Current at 10ms: 80A
- Maximum Off-State Leakage: 1.5mA
- Maximum On-State Voltage Drop: 1.5V rms
- Dielectric Strength (Input/Output): 2500V rms
- Insulation Resistance: 1000MQ @ 500V DC
- Ambient Operating Temperature: -30°C to +80°C
- Ambient Storage Temperature: -30°C to +100°C
- Weight: 4g
- RoHS Compliant
Buy the Buy Multicomp Solid State Relay Part Number MC002258 Online
Enhance your control systems with this reliable solid state relay, supporting up to 2A load current and 240V AC output. Designed for PCB and PLC applications, it features zero crossing switching to reduce electrical noise, optoelectronic isolation for safety, and control voltages of 5V or 24V DC. Its compact size and RoHS compliance make it ideal for space-constrained, eco-friendly industrial environments. Easy to install with DIN rail mounting, ensuring reliable operation in demanding automation projects.
Order your Multicomp SeriesMC002258 solid state relay today and ensure efficient, reliable switching for your industrial automation needs.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MC002258?
You can click on the BUY or RFQ button to purchase MC002258 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MC002258?
You can download the MC002258 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MC002258?
MULTICOMP PRO
