MULTICOMP-PRO MC002323 Solid State Relay
These panel mount solid state relays are designed for single-phase AC output applications, supporting load voltages from 240V to 600V AC and current ratings up to 125A. They feature zero crossing or random-on operation, with options for TRIAC or SCR output structures. Suitable for industrial automation, HVAC, food processing, and machinery control, they provide dielectric strength up to 24,000V, quick switching times, and optional built-in MOV or TVS protection. Their robust design ensures reliable performance over a wide temperature range from -30°C to +80°C, making them ideal for demanding environments.
MULTICOMP-PRO MC002323 Solid State Relay Specifications:
- Load Current: 10A to 125A
- Load Voltage Range: 240V AC to 600V AC
- Control Voltage: 4-32V DC or 90-280V AC
- Dielectric Strength: 24,000V AC rms
- Maximum Surge Current: 1250A @10ms
- Off-state Leakage Current: 5mA
- Maximum Off-state Voltage: 600V pk
- Operating Temperature: -30°C to +80°C
- Storage Temperature: -30°C to +100°C
- Weight: 96g to 180g depending on options
- Input/Output Isolation: 2,500Vrms
- Dielectric Strength (Input/Output): 4,000Vrms
- Transient Overvoltage: up to 1600Vpk
- Switching Time: 10-40ms depending on input
- Build-in MOV or TVS option available
Buy the Buy Multicomp Pro Panel Mount Solid State Relay Part Number MC002323 Online
Get your high-performance solid state relay from Multicomp Pro online today to improve your machinery control and automation systems. Designed for single-phase AC loads, it supports voltages up to 600V and currents up to 125A. With options for zero crossing or random-on operation, TRIAC or SCR output, and built-in protection features, this relay ensures dependable switching in demanding environments. Fast switching times and wide temperature tolerance make it suitable for HVAC, industrial automation, and food processing equipment. Purchase now for fast, secure delivery and peace of mind.
Order your Multicomp Pro Panel Mount Solid State Relay MC002323 today and ensure reliable, high-current switching for your industrial projects.
Frequently Asked Questions
Where can I buy MULTICOMP-PRO MC002323?
You can click on the BUY or RFQ button to purchase MC002323 from an authorized MULTICOMP-PRO distributor.
How do I troubleshoot issues or seek technical support for part MC002323?
You can download the MC002323 datasheet or visit the MULTICOMP-PRO website for support.
Who is the manufacturer of MC002323?
MULTICOMP-PRO
