MULTICOMP PRO MC002395 Microload Limit Switch
Microload switches are highly durable limit switches designed for industrial applications, offering a large switching capacity of 15A with high repeat accuracy, diverse actuator options, and a wide operating speed range. With IP00 protection degree, they feature robust insulation resistance, dielectric strength, and vibration resistance, suitable for various environments. These switches support multiple configurations such as panel mount, roller, hinge, and plunger types, and are rated for 250V AC or 15A, ensuring reliable performance in automation, machinery, and control systems. Their mechanical durability reaches 20 million operations for extended service life.
MULTICOMP PRO MC002395 Microload Limit Switch Specifications:
- Degree of protection: IP00
- IEC 60947-5-1 ratings: 250V AC / 15A, 480V AC / 15A
- UL508 ratings: 0.5A/125V DC, 0.25A/250V DC, 1/8HP/120V AC, 1/4HP/240V AC, 1/2HP/480V AC
- Mechanical operations: minimum 20 million
- Electrical operations: minimum 500,000
- Operating Speed: 0.01mm to 1m/s
- Operating Frequency: Mechanical 240/min, Electrical 20/min
- Insulation Resistance: ≥100MQ at 500V DC
- Contact Resistance: ≤15mΩ
- Dielectric Strength: 2000V between terminals and ground
- Rated Insulation Voltage: 250V AC
- Ambient Temperature: -25°C to +80°C
- Vibration Resistance: 10–55Hz, 1,000m/s²
- Shock Resistance: 300m/s² (malfunction), 1,000m/s² (destruction)
- Humidity Range: 35% to 85% RH
Buy the Multicomp Series Microload Switch: MC002395
Enhance your automation setup with the durable Microload Limit Switch designed for industrial applications. Offering a switching capacity of 15A, high accuracy, and versatile actuator options, this switch supports extensive operation life exceeding 20 million mechanical cycles. Rated at 250V AC and 15A, it withstands harsh environments with an IP00 protection degree and broad temperature range. Easy to install and suitable for machinery, control systems, and automation projects, order online now to boost your productivity and ensure dependable performance.
Order your Multicomp Series Microload Switch MC002395 today and ensure reliable switching performance for your industrial control needs.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MC002395?
You can click on the BUY or RFQ button to purchase MC002395 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MC002395?
You can download the MC002395 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MC002395?
MULTICOMP PRO
