MULTICOMP PRO MC011363 Green LED Lamp
The 3mm round LED lamp in ultra green emits a vibrant wavelength of approximately 525 nm, making it ideal for indicator and display applications. It features a clear water lens with a 30° viewing angle and a luminous intensity of up to 15,000 mcd at 20mA. Designed with InGaN dice material, it is RoHS compliant and suitable for operating temperatures ranging from -40°C to +85°C. The LED operates at a forward voltage of 3.2V, with a maximum power dissipation of 85 mW. It supports a peak forward current of 100 mA for duty cycles at 1 kHz, ensuring reliable performance in various environments.
MULTICOMP PRO MC011363 Green LED Lamp Specifications:
- Dice Material: InGaN
- Emitted Colour: Ultra Green
- Lens Colour: Water Clear
- Peak Wavelength: 525 nm
- Viewing Angle: 30 Degrees
- Luminous Intensity (IV): 15000 mcd
- Reverse Voltage: 5 Volt
- Reverse Current: 10 μA at VR = 5V
- Max Storage Temperature: +100°C
- Operating Temperature Range: -40°C to +85°C
- Lead Soldering Temperature: 260°C for 5 seconds at 4.6mm from body
- Forward Voltage: 3.2V typical at 20mA
- Power Dissipation: 85 mW
- Peak Forward Current: 100 mA at 1/10 duty cycle, 1kHz
- Recommended Operating Current: 20 mA
Buy the Buy Multicomp Ultra Green 3mm Round LED Part Number MC011363 Online
Purchase the high-brightness Ultra Green 3mm LED lamp online today to benefit from quick delivery and reliable performance. Ideal for indicator lighting, displays, and electronic projects, this LED features a water-clear lens with a 30° viewing angle and 15,000 mcd luminous intensity. Designed with RoHS compliance, it supports operation within -40°C to +85°C temperatures. With a peak wavelength of 525 nm and low reverse current, this LED ensures efficient operation in all your applications. Don't miss out—order now for quality and dependability.
Order your Multicomp SeriesMC011363 Ultra Green 3mm LED today and enhance your indicator and display projects with dependable brightness and longevity.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MC011363?
You can click on the BUY or RFQ button to purchase MC011363 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MC011363?
You can download the MC011363 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MC011363?
MULTICOMP PRO
