MULTICOMP-PRO MC0125W12061680R Thick Film Resistor
The Multicomp Pro MC series thick film chip resistors offer resistance values from 1 Ohm to 10 MΩ, including E96 and E24 series, in standard sizes 0402, 0603, 0805, and 1206. They are compact, lightweight, and suitable for wave and reflow soldering, reducing assembly costs. Max working voltages are 50V, 150V, and 200V depending on size. They feature tolerance levels of ±1%, ±2%, and ±5%, power ratings up to 125mW, with temperature coefficients from ±400ppm/°C to ±100ppm/°C. Operating temperatures range from -55°C to +155°C, ensuring reliable performance in diverse applications.
MULTICOMP-PRO MC0125W12061680R Thick Film Resistor Specifications:
- Resistance Range: 1Ω to 10MΩ
- Sizes: 0402, 0603, 0805, 1206
- Tolerance: ±1%, ±2%, ±5%
- Power Ratings: 62.5mW, 100mW, 125mW
- Max Working Voltage: 50V (0402, 0603), 150V (0805), 200V (1206)
- Temperature Coefficient: ±400ppm/°C (1Ω-10Ω), ±100ppm/°C (>100Ω)
- Operating Temperature Range: -55°C to +155°C
- Soldering: Suitable for wave and reflow
- Number of Resistance Values: Wide range including E24, E96 series
- Application Suitability: Automated assembly, high-reliability devices
Buy the Buy Multicomp Pro MC0125W12061680R Thick Film Resistor Part Number 1206
Get the robust and precise thick film chip resistors from Multicomp Pro MC series directly online. Designed for automated assembly with sizes 0402, 0603, 0805, and 1206, these resistors deliver resistance from 1Ω to 10MΩ. They feature low weight, high reliability, and are suitable for wave and reflow soldering to reduce manufacturing costs. With various tolerances, power ratings, and wide operating temperature ranges, they are the perfect choice for demanding industrial and consumer electronics applications. Buy now to ensure your circuits perform reliably under the toughest conditions.
Order your Multicomp Pro MC series thick film chip resistor today and give your projects the dependable quality they deserve.
Frequently Asked Questions
Where can I buy MULTICOMP-PRO MC0125W12061680R?
You can click on the BUY or RFQ button to purchase MC0125W12061680R from an authorized MULTICOMP-PRO distributor.
How do I troubleshoot issues or seek technical support for part MC0125W12061680R?
You can download the MC0125W12061680R datasheet or visit the MULTICOMP-PRO website for support.
Who is the manufacturer of MC0125W12061680R?
MULTICOMP-PRO
