MULTICOMP-PRO MCHVS1S08G Pin Header
This 1.27mm pitch pin header with cap is a vertical, SMD type connector designed for reliable electrical connections in PCB applications. It features a high-temperature nylon insulation rated for temperatures from -25°C to +105°C, with gold-plated copper contacts ensuring low contact resistance of 20mΩ maximum. Rated for 1A current and 50V voltage, it withstands up to 500V for one minute. Its compact dimensions and robust construction make it suitable for precise, high-quality electronic assemblies.
MULTICOMP-PRO MCHVS1S08G Pin Header Specifications:
- Current Rating: 1A AC/DC
- Voltage Rating: 50V AC/DC
- Contact Resistance: 20mΩ Max
- Insulation Resistance: 1000MΩ Min
- Withstanding Voltage: 500V for one minute
- Operating Temperature Range: -25°C to +105°C
- Material: High temperature plastic (Nylon 9T UL94V-0)
- Color: Black
- Contact Material: Copper Alloy
- Plating: Gold Plated
- Pin Pitch: 1.27mm
- Number of Positions: 3 to 10
- Height: 5.1mm
- Mounting Type: SMD Vertical
- RoHS Compliant
- Dimensions: Millimetres
Buy the Buy Multicomp Pin Header Part Number MCHVS1S08G Online
Enhance your electronic projects with this high-quality 1.27mm pitch pin header featuring a durable cap. Suitable for vertical SMD mounting, it offers reliable electrical performance with gold-plated contacts that ensure low contact resistance. Rated for 1A current and 50V voltage, it withstands up to 500V for one minute, performing reliably across -25°C to +105°C. Its compact, robust design ensures easy installation and long-term durability in various PCB applications, making it an essential component for professional electronic assembly.
Get Multicomp pin header MCHVS1S08G today—designed for durable, reliable PCB connections and efficient electronic assembly.
Frequently Asked Questions
Where can I buy MULTICOMP-PRO MCHVS1S08G?
You can click on the BUY or RFQ button to purchase MCHVS1S08G from an authorized MULTICOMP-PRO distributor.
How do I troubleshoot issues or seek technical support for part MCHVS1S08G?
You can download the MCHVS1S08G datasheet or visit the MULTICOMP-PRO website for support.
Who is the manufacturer of MCHVS1S08G?
MULTICOMP-PRO
