MULTICOMP-PRO MC1010501B RF Connector Adapter
The 3.5mm Plug to SMA bulkhead jack adapter is a high-frequency RF connector designed for precise signal transmission in communications, aerospace, and military applications. Featuring a stainless steel body and beryllium copper contacts, it offers excellent durability and electrical performance. With a frequency range up to 18GHz and an impedance of 50Ω, it supports working voltages up to 335V and operates reliably between -65°C and +165°C. This compact, reliable adapter ensures optimal performance in demanding environments and critical applications requiring high signal integrity.
MULTICOMP-PRO MC1010501B RF Connector Adapter Specifications:
- Frequency Range: DC-18GHz
- Impedance: 50Ω
- Working Voltage: 335V Max
- Proof Voltage: 750V
- VSWR: 1.23 Max. at 18GHz, 2.1 Max. at 6GHz
- Body Material: Stainless Steel per JIS SUS 303
- Center Contact Material: Beryllium Copper per ASTM B196 UNS C17300
- Insulation Material: PTFE per ATM D1457 and ASTM D1710
- Environmental Operating Temperature: -65°C to +165°C
- Interface Standard: MIL-STD-348A
- Dimensions: Refer to diagram with mm measurements
- Connector Style: SMA bulkhead jack
- Part Number: MC-1010501B
Buy the Premier RF Solutions MC1010501B – Reliable SMA Bulkhead Adapter for Industrial Applications
Discover the high-performance MC1010501B SMA bulkhead jack adapter designed for optimal signal integrity in advanced communication, aerospace, defense, and networking projects. Constructed with durable stainless steel and beryllium copper components, it offers a frequency range up to 18GHz, impedance of 50Ω, and supports voltages up to 335V. Its wide operating temperature from -65°C to +165°C ensures reliable performance in harsh conditions. Ideal for critical applications requiring precise, high-frequency connections, this adapter guarantees durability and exceptional electrical performance.
Buy Premier RF Solutions MC1010501B high-frequency SMA bulkhead adapter now and experience unmatched reliability and performance in demanding industrial environments.
Frequently Asked Questions
Where can I buy MULTICOMP-PRO MC1010501B?
You can click on the BUY or RFQ button to purchase MC1010501B from an authorized MULTICOMP-PRO distributor.
How do I troubleshoot issues or seek technical support for part MC1010501B?
You can download the MC1010501B datasheet or visit the MULTICOMP-PRO website for support.
Who is the manufacturer of MC1010501B?
MULTICOMP-PRO
