MULTICOMP PRO MC14722 Adjustable Wire-Wound Resistor
The MC14640 is a high power, adjustable wire-wound resistor with a tubular ceramic core and lead-free vitreous enamel coating, designed for precision applications. It features solder-coated axial terminals and a power rating dependent on the chassis mounting area and ambient temperature. Suitable for high current capacity, it can withstand overload conditions of 5 times rated wattage for 5 seconds. Its temperature coefficient varies from +20 ppm/°C to +90 ppm/°C, with dielectric withstand voltages up to 2250V AC. Compact and robust, it offers reliable performance across temperature ranges from -55°C to +275°C.
MULTICOMP PRO MC14722 Adjustable Wire-Wound Resistor Specifications:
- Housing: Metal, Anodized Aluminium
- Internal Coating: Silicone
- Core: Ceramic
- Terminals: Solder-coated axial lead
- Power Rating: Based on chassis mounting area and temperature stability
- Overload Capability: 5 times rated wattage for 5 seconds
- Temperature Coefficient: >1Q +90ppm/°C, 1 to 9.990 +50 ppm/°C, 10Q and over +20 ppm/°C
- Dielectric withstanding Voltage: 1000V AC at 5W & 10W, 2250V AC at 25W & 50W
- Inductance: Single layer inductive windings
- Dimensions: Length varies with wattage, e.g., 10 Watt 0.562 inches, 50 Watt 1.563 inches
- Temperature Range: -55°C to +275°C
- Wattage Derating: Linearly from 100% at +25°C to 0% at +275°C
Buy the Multicomp Series Resistor: Adjustable Wire-Wound: MC14640
Purchase the Multicomp MC14640 adjustable wire-wound resistor online today to ensure reliable high power performance in your electronic or industrial projects. Designed with a ceramic core and solder-coated terminals, this resistor offers exceptional durability and temperature stability up to 275°C. With a power rating that adjusts based on mounting conditions and ambient temperature, it guarantees high current handling and overload capacity. Ideal for precision applications requiring stable, long-lasting resistance for various demanding environments.
Get Multicomp MC14640 today—built for high power and precision resistor applications.
