MULTICOMP PRO MC20050811 Terminal Block
The MC200-50811 is an 11-pole Euro-style pluggable terminal block with a 90° entry angle, designed for plug side connections. Part of the MC series, it offers reliable, flexible wiring with screw connections supporting conductors up to 12 AWG. The terminal block ensures easy modifications and simplified installation, making it ideal for industrial automation and control systems. Constructed with polyamide body, phosphor tin plated bronze contacts, and steel Ni Plated screws, it meets RoHS standards and withstands temperatures from -40°C to +105°C. The high current rating of 16A and insulation withstand voltage of 2000V enable safe, efficient electrical connections in demanding environments.
MULTICOMP PRO MC20050811 Terminal Block Specifications:
- Current Rating: 16Amp
- Insulation Withstands Voltage: AC 2000V min.
- Insulation Resistance: >2,000MΩ DC500V
- Operation Temperature: -40°C to +105°C
- Wire Range: 14AWG to 24AWG
- Screw Torque: 4.5lb-inch
- Body Material: Polyamide
- Contact Material: Phosphor Tin Plated Bronze
- Clamp Material: Brass, Ni Plated
- Screw Material: Steel, Ni Plated
- Dimensions: 2.54mm (0.100777 inches) per pole
- Poles: 11
- Part Number: MC200-50811
- RoHS Compliant
Buy the Multicomp MC200-50811 U–Reliable Terminal Blocks for Industrial Applications
Purchase the Multicomp MC200-50811 terminal block online today and ensure secure, reliable connections in your industrial projects. With 11 poles, screw connections supporting up to 12 AWG conductors, and construction compliant with RoHS standards, this terminal block offers excellent electrical performance across a wide temperature range from -40°C to +105°C. Its durable polyamide body, high-quality brass contacts, and steel screws provide stability and safety in demanding environments. Ideal for quick installation and easy modifications, enhance your wiring system reliability now.
Buy Multicomp MC200-50811 now and experience unmatched reliability and performance with a robust 11-pole terminal block designed for industrial automation.
