MULTICOMP PRO MC202103M130B20C0B Ceramic Disc Capacitor
The MC202103M130B20C0B is a ceramic disc capacitor featuring straight long leads, epoxy resin coating, and Z5U dielectric. It offers reliable performance suitable for various electronic applications. Designed for high voltage operation up to 3 KV, this capacitor maintains stable capacitance within +10°C to +85°C, with a capacitance tolerance of ±20%. Its dimensions include a diameter of 13 mm and a lead length of 20 mm, with a lead diameter of 0.6 mm. This component undergoes rigorous testing for withstand voltage, insulation resistance, and thermal stability, making it ideal for demanding electronic environments.
MULTICOMP PRO MC202103M130B20C0B Ceramic Disc Capacitor Specifications:
- Rated Voltage: 3 KV DC
- Capacitance: 102 = 100 pF
- Tolerance: ±20%
- Diameter: 13 mm
- Lead Length: 20 mm ±1 mm
- Lead Diameter: 0.6 mm +0.06 mm
- Lead Style: Straight long lead
- Dielectric: Z5U (Class II)
- Operating Temperature Range: +10°C to +85°C
- Capacitance Change: Within +22% to -56% over temperature
- Withstand Voltage: 3 KV
- Insulation Resistance: ≥ 1,000 MΩ after test
- Dissipation Factor: Below 2.5%
- Test Conditions: Temperature 5°C to 35°C, humidity 45-85%
Buy the Buy Multicomp Ceramic Disc Capacitor Part Number MC202103M130B20C0B Online
Secure your Multicomp ceramic disc capacitor MC202103M130B20C0B online today. Perfect for high voltage applications with epoxy resin coating, Z5U dielectric, and outstanding stability. This 3 KV rated capacitor offers excellent reliability with a diameter of 13 mm and a lead length of 20 mm, suitable for demanding electronic environments. Its robust construction ensures consistent performance over temperature, making it an essential component for your projects. Buy now and benefit from fast delivery and genuine quality assurance.
Order your Multicomp ceramic disc capacitor MC202103M130B20C0B today and enhance your electronic projects with reliable high voltage performance and durable construction.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MC202103M130B20C0B?
You can click on the BUY or RFQ button to purchase MC202103M130B20C0B from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MC202103M130B20C0B?
You can download the MC202103M130B20C0B datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MC202103M130B20C0B?
MULTICOMP PRO
