MULTICOMP PRO MC20437 Yellow Indicator LED
This 8mm round lens LED emits yellow light and is suited for various indication and lighting applications. It features high intensity, rugged reliability, and is compliant with RoHS standards. The LED has a luminous intensity of 70 millicandelas at 20mA, a viewing angle of 60 degrees, and a peak wavelength of 590 nm. It operates within -25°C to +80°C and can withstand up to 260°C soldering temperature. Its durable construction makes it ideal for industrial and electronic signage use, offering consistent performance and energy efficiency.
MULTICOMP PRO MC20437 Yellow Indicator LED Specifications:
- Luminous Intensity: 70 mcd at 20mA
- Viewing Angle: 60°
- Peak Wavelength: 590 nm
- Dominant Wavelength: 585 nm
- Forward Voltage: 2 - 2.5 V
- Maximum Power Dissipation: 100 mW
- Operating Temperature Range: -25°C to +80°C
- Storage Temperature Range: -40°C to +100°C
- Reverse Voltage: 5 V
- Lead Soldering Temperature: 260°C for 5 seconds
- Lead Spacing: as per standard 8mm package
- Material: GaAsP chip, diffused lens
- RoHS Compliant
- Peak Forward Current: 100 mA
- Continuous Forward Current: 30 mA
- Derating: 0.4 mA/°C from 50°C
Buy the Multicomp 8mm Standard LED – Reliable Yellow Indicator for Industrial Applications
Discover the high-quality yellow indicator LED with an 8mm round lens designed for reliable performance in industrial and electronic applications. Featuring a luminous intensity of 70 millicandelas at 20mA, a wide viewing angle of 60 degrees, and a peak wavelength of 590 nm, this rugged LED meets RoHS standards for eco-friendliness. Its durable construction and high maximum power dissipation ensure long-lasting operation even in demanding environments. Ideal for indicators, displays, and signaling systems, it offers energy-efficient illumination with consistent brightness and reliability.
Get Multicomp 8mm Standard LED today—built for precision, high brightness, and long-lasting durability in industrial lighting and signaling.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MC20437?
You can click on the BUY or RFQ button to purchase MC20437 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MC20437?
You can download the MC20437 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MC20437?
MULTICOMP PRO
