MULTICOMP PRO MC25142 Industrial Control Relay
Multicomp Pro relay is a versatile industrial switching component with a contact form C, made of Ag Alloy, rated for resistive loads of 16A at 250V AC and 30V DC. It features rapid operation times up to 10ms, mechanical durability of 20 million cycles, and electrical endurance of 100,000 operations, making it suitable for demanding control systems. Its robust insulation resistance of 10,000MQ, dielectric strength up to 1000V AC, and high shock and vibration resistance ensure reliable performance across various environments. Ideal for automation, industrial control, and manufacturing applications, this relay offers dependable switching for both resistive and inductive loads.
MULTICOMP PRO MC25142 Industrial Control Relay Specifications:
- Contact Material: Ag Alloy
- Contact Form: 21 form C
- Contact Rating Resistive: 16A 250V AC / 30V DC
- Contact Rating Inductive: 8A 250V AC Cos φ = 0.4
- Max. Switching Voltage: 380V AC / 30V DC
- Max. Switching Power: 4000VA, 240W
- Electrical Life: 100,000 operations
- Mechanical Life: 20,000,000 operations
- Insulation Resistance: 10,000MQ 500V DC
- Dielectric Strength: 1000V AC 1 min between open contacts, 5000V AC 1 min coil to contacts
- Operate Time: Max 10ms
- Release Time: Max 5ms
- Operate Temperature: -40°C to +85°C
- Shock Resistance: 1000m/s² endurance
- Vibration Resistance: 10-55Hz, 1.5mm double amplitude endurance
- Humidity: 35% to 95% RH at +40°C
- Max Contact Resistance: 100mΩ at 6V DC 1A
- Dimensions: Millimeters (detailed diagrams available)
Buy the Buy multicomp Pro Relay Part Number MC25142 Online
Purchase the multicomp Pro relay MC25142 online today and experience dependable switching performance for automation and control systems. This high-quality relay features Ag Alloy contacts, resistive load capacity of 16A at 250V AC, and an inductive load rating of 8A. Its rapid operate time of up to 10ms ensures quick response, while the robust construction guarantees long-lasting durability through millions of operations. Ideal for manufacturing, automation, and industrial control projects, this relay offers reliable, efficient switching with precise control and safe operation. Order now for fast shipment and expert support.
Get multicomp Pro relay MC25142 today—designed for high reliability and fast switching in industrial control systems.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MC25142?
You can click on the BUY or RFQ button to purchase MC25142 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MC25142?
You can download the MC25142 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MC25142?
MULTICOMP PRO
