MULTICOMP PRO MC302222M080B20C7B High-Voltage Ceramic Capacitor
This high-quality ceramic disc capacitor from the Multicomp Pro series is designed for high-voltage applications up to 3 KV, offering reliable performance with a capacitance of 100 pF. It features a lead diameter of 0.6 +0.06 mm, a 20mm lead length with epoxy resin coating for mechanical stability, and a diameter of 8 mm. Designed to operate efficiently within a temperature range of +10°C to +85°C, it ensures low dissipation factor below 2.5%, excellent insulation resistance, and robust withstand voltage capabilities, making it ideal for various industrial and electronic applications requiring high voltage reliability.
MULTICOMP PRO MC302222M080B20C7B High-Voltage Ceramic Capacitor Specifications:
- Rated Voltage: 3 KV de
- Capacitance: 100 pF
- Tolerance: +20%
- Lead Diameter: 0.6 +0.06 mm
- Lead Length: 20 mm with epoxy resin coating
- Product Diameter: 8 mm
- Maximum Lead Extension (e): 3 mm
- Operating Temperature: +10°C to +85°C
- Dissipation Factor: Below 2.5%
- Insulation Resistance: Minimum 10,000 MΩ
- Test Voltage (withstand): 6 KV de for 1-5 seconds
- Post-Test Appearance: No abnormalities
- Humidity Resistance: Capacitance change within +20%, resistance ≥ 500 MΩ
- Temperature Cycling: 5 cycles between -25°C and +85°C
- Mechanical Strength: No breakdown under specified load
Buy the Multicomp 302222M080B20C7B – Reliable High-Voltage Ceramic Capacitor for Industrial Applications
Enhance your electronic designs with our high-voltage ceramic capacitor from the Multicomp series, rated at 3 KV with 100 pF capacitance. Featuring robust epoxy-coated leads, a diameter of 8 mm, and operating temperatures from +10°C to +85°C, this capacitor guarantees reliable insulation resistance and low dissipation factor. Perfect for industrial and high-voltage applications, it’s built to withstand demanding environments. Purchase online today and enjoy fast shipping, quality assurance, and the confidence of using a trusted component for your critical projects.
Order your Multicomp 302222M080B20C7B high-voltage ceramic capacitor today and ensure your projects benefit from dependable performance and long-term durability.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MC302222M080B20C7B?
You can click on the BUY or RFQ button to purchase MC302222M080B20C7B from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MC302222M080B20C7B?
You can download the MC302222M080B20C7B datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MC302222M080B20C7B?
MULTICOMP PRO
