MULTICOMP-PRO MC34343 Right Angle SMT Headers
3mm right angle SMT headers are essential for compact electronic connections, featuring reliable copper alloy tin-plated pins, Nylon 46 insulators, and optimized for surface-mount technology. These headers support voltages up to 250V AC/DC, operate efficiently within -25°C to +105°C, and provide minimal contact resistance over 10mΩ. Designed for precision PCB mounting, they come in various configurations including 10, 12, and 16 positions with dimensions optimized for tight spaces. Ideal for automation, control systems, and electronic device assembly, these headers ensure secure electrical contacts and durability in demanding environments.
MULTICOMP-PRO MC34343 Right Angle SMT Headers Specifications:
- Current Rating: SAAC/DC
- Voltage Rating: 250V AC/DC
- Max. Contact Resistance: > 10mΩ
- Min. Insulation Resistance: 1,000MΩ
- Withstanding Voltage: 1,500V AC for one minute
- Operating Temperature Range: -25°C to +105°C
- Wafer Insulator: Nylon 46
- Contact Pin Material: Copper Alloy Tin Plated
- Dimension A: 20.20 mm (for 10-position), 21.7 mm (for 12-position), 27.7 mm (for 16-position)
- Dimension B: 12 mm, 15 mm, 21 mm respectively
- Board Lock: 0.60 mm
- Applicable for surface-mount PCB mounting
- Configurations: 10, 12, 16 positions available
- RoHS compliant
Buy the Buy Multicomp SMT Header Part Number MC34343 Online
Purchase the Multicomp Pro right angle SMT headers online today. These high-quality, reliable PCB connectors support voltages up to 250V AC/DC and are designed for durability in tight spaces. With configurations for 10, 12, and 16 positions, they feature copper alloy tin-plated pins and Nylon 46 insulators to ensure excellent electrical contact and mechanical stability. Ideal for automation, control panels, and electronic devices, order now for fast delivery and dependable performance in your projects.
Buy Multicomp MC34343 now and experience reliable surface-mount connections for compact electronic assemblies.
Frequently Asked Questions
Where can I buy MULTICOMP-PRO MC34343?
You can click on the BUY or RFQ button to purchase MC34343 from an authorized MULTICOMP-PRO distributor.
How do I troubleshoot issues or seek technical support for part MC34343?
You can download the MC34343 datasheet or visit the MULTICOMP-PRO website for support.
Who is the manufacturer of MC34343?
MULTICOMP-PRO
