MULTICOMP PRO MP005709 Ceramic Cartridge Fuse
This time-lag ceramic cartridge fuse features axial leaded design, with a body made of ceramic and nickel-plated brass caps, ideal for circuit protection in various electrical devices. Measuring 5.2mm x 20mm, it provides reliable operation with an amperage range from 1A to 10A, and a control voltage up to 350V. Designed for high-temperature environments from -55°C to 125°C, it ensures safety and durability with a breaking capacity of 1500 amperes at 250V AC. Suitable for industrial applications requiring fast or slow blow characteristics, it complies with RoHS and recognized agency approvals.
MULTICOMP PRO MP005709 Ceramic Cartridge Fuse Specifications:
- Body Material: Ceramic
- Caps Material: Nickel Plated Brass
- Leads Wire Diameter: 0.65 mm (6.3A and below), 0.8 mm (8A/10A)
- Dimensions: 5.2mm x 20mm
- Operating Temperature: -55°C to 125°C
- Interrupting Rating: 1500 amperes at 250V AC
- Voltage Rating: 350V
- Agency Approvals: Recognized component in US, Canada, TUV, PSE, KTL, cac
- Rated Current: 1A to 10A
- Resistance Drop: 0.0744 mV (1A), 0.0478 mV (2A), 0.0385 mV (2.5A), 0.0265 mV (3.15A), 0.0175 mV (4A), 0.0130 mV (5A), 0.0075 mV (8A)
- Max Melting Time: 95ms (1A-3.15A), 30min (4A-6.3A), 10ms (8A-10A)
Buy the Farnell MP005709 – Reliable Circuit Protection Fuse for Industrial Applications
Order the ceramic cartridge fuse today to ensure reliable circuit protection in industrial and electrical systems. Featuring axial leads, high-temperature tolerance, and recognized agency approvals, this fuse guarantees safety and durability. Perfect for applications requiring fast or slow blow characteristics, with amperages from 1A to 10A and voltage ratings up to 350V. Its compact size of 5.2mm x 20mm makes it ideal for space-constrained environments while providing consistent performance under demanding conditions. Purchase online now for quick delivery and guaranteed quality.
Get Farnell MP005709 today—built for precision and long-lasting durability.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MP005709?
You can click on the BUY or RFQ button to purchase MP005709 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MP005709?
You can download the MP005709 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MP005709?
MULTICOMP PRO
