MULTICOMP PRO MC34911 Wire-to-Wire Connector
The MC34911 is a 3-way panel mount plug connector with a durable nylon 66 insulator housing and tin-plated phosphor bronze or brass crimp terminals. It supports wire sizes from 26AWG to 16AWG and features a compact 4.2mm pitch spacing, ideal for industrial wiring and automation systems. This connector offers a current rating of 9A DC/AC, low contact resistance of 10mΩ, and high insulation resistance of 1000 megaohms. It withstands voltages up to 1500V AC/minute, operates between -40°C to +105°C, and is suitable for robust industrial connectivity.
MULTICOMP PRO MC34911 Wire-to-Wire Connector Specifications:
- Housing Material: Nylon 66
- Terminal Material: Phosphor Bronze or Brass, Tin Plated
- Wire Size: 26AWG to 16AWG
- Pitch Spacing: 4.2mm
- Current Rating: 9A AC/DC
- Contact Resistance: 10mΩ Max.
- Insulation Resistance: 1,000MΩ Min.
- Withstand Voltage: 1500VAC per minute
- Operating Temperature Range: -40°C to +105°C
- Maximum Panel Thickness: 2mm
Buy the Multicomp 2259A – Reliable Connectors for Industrial Applications
Purchase the Multicomp 2259A series connectors online today to ensure dependable, high-quality connections for your industrial automation and control projects. These connectors feature a robust nylon housing, tin-plated terminals, and support wire sizes from 26AWG to 16AWG, making them ideal for various applications. With a current rating of 9A and excellent insulation resistance, they provide safe and durable electrical connectivity. Order now for fast shipping, competitive pricing, and trusted quality guaranteed to meet industrial standards.
Buy Multicomp 2259A now and experience unmatched reliability and performance in industrial wiring solutions.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MC34911?
You can click on the BUY or RFQ button to purchase MC34911 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MC34911?
You can download the MC34911 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MC34911?
MULTICOMP PRO
