MULTICOMP PRO MCCMA4SDC12VCE Automotive Relay
The automotive relay is a high-current SPDT switch designed for vehicle electrical systems, operating at 12V DC with a coil resistance of 90 ohms. It features Ag alloy contacts rated for 830A at 14V DC resistive, capable of switching up to 75V DC and 40A current. With a coil power of 1.6W, it provides reliable operation with a maximum operate time of 5ms and release time of 3ms. Its compact design weighs approximately 21 grams, offering electrical endurance of 100,000 cycles and mechanical life up to 10 million cycles. Suitable for automotive and industrial applications.
MULTICOMP PRO MCCMA4SDC12VCE Automotive Relay Specifications:
- Nominal Voltage: 12V DC
- Coil Resistance: 90 ohms
- Operate Voltage: 7.2V
- Release Voltage: 1.2V
- Coil Power: 1,600mW
- Contact Form: SPDT (C-1 form C)
- Contact Material: Ag Alloy
- Contact Rating: 830A at 14V DC Resistive
- Max Switching Voltage: 75V DC
- Max Switching Current: 40A
- Max Switching Power: 420W
- Max Load Current: 12V DC, 40A
- Max Make Current: 100A
- Max Break Current: 40A
- Contact Resistance: 100mΩ at 6V DC 1A
- Electrical Life: 100,000 operations
- Mechanical Life: 10,000,000 operations
- Insulation Resistance: ≥100 MΩ at 500V DC
- Dielectric Strength: 500V AC for 1 min
- Operate Time: ≤5ms
- Release Time: ≤3ms
- Operate Temperature: -40°C to +85°C
- Shock Resistance: 100 m/s² min.
- Mis-operation Shock: 1,000 m/s² min.
- Vibration Resistance: 10-55 Hz, ±1.5 mm amplitude
- Weight: Approximately 21g
Buy the Multicomp Series Automotive Relay: MCCMA4SDC12VCE
Enhance your automotive electrical systems with our high-current automotive relay, designed for durability and reliable switching at 12V DC. Featuring Ag alloy contacts rated for 830A at 14V, it handles up to 75V DC and 40A loads comfortably. With a coil power of 1.6W, fast operation times, and an electrical life of 100,000 cycles, it ensures long-lasting performance under demanding conditions. Ideal for vehicle automation, industrial applications, and heavy-duty switching tasks, this relay offers robust construction and precise switching capabilities for professional installations.
Buy Multicomp Series Automotive Relay MCCMA4SDC12VCE now and experience unmatched reliability and industrial-grade performance.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MCCMA4SDC12VCE?
You can click on the BUY or RFQ button to purchase MCCMA4SDC12VCE from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MCCMA4SDC12VCE?
You can download the MCCMA4SDC12VCE datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MCCMA4SDC12VCE?
MULTICOMP PRO
