MULTICOMP PRO MCHVS1S07G Pin Header
This 1.27mm pin header with cap features a single row, vertical SMD design suitable for reliable PCB connections in compact electronic assemblies. It supports a current rating of 1A AC/DC and a voltage rating of 50V AC/DC. Crafted from high-temperature nylon (UL94V-0), the insulator is black, while the contact is a gold-plated copper alloy ensuring excellent conductivity and corrosion resistance. The component withstands voltages up to 500V for one minute, with a temperature range from -25°C to +105°C. Its dimensions and layout facilitate easy mounting and secure positioning on electronic circuits, perfect for automation and control systems.
MULTICOMP PRO MCHVS1S07G Pin Header Specifications:
- Current Rating: 1A AC/DC
- Voltage Rating: 50V AC/DC
- Contact Resistance: 20mΩ Max
- Insulation Resistance: 1000MΩ Min
- Withstanding Voltage: 500V for one minute
- Operating Temperature Range: -25°C to +105°C
- Insulator Material: High temp. Plastic (Nylon 9T UL94V-0)
- Color: Black
- Contact Material: Copper Alloy
- Contact Finish: Gold Plated
- Dimensions: 1.27mm pitch, 5.1mm height, 3 to 10 positions available, single row, SMD type
- RoHS Compliant
- Designed for SMT applications, with recommended PCB layout for secure mounting
Buy the Multicomp 1.27mm – Reliable Pin Header for Industrial Applications
Enhance your electronic projects with this high-quality 1.27mm vertical pin header. Featuring gold-plated contacts and a durable nylon insulator, it ensures reliable electrical connections in industrial, automation, and control systems. Rated for 1A at 50V and capable of withstanding 500V for a minute, the component operates across a temperature range of -25°C to +105°C. Easy to mount on SMT boards, this header supports secure and durable connections for complex electronic applications. Order online today for quick, reliable delivery.
Buy Multicomp 1.27mm pin header with cap now and experience unmatched reliability for your PCB connections and electronic assemblies.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MCHVS1S07G?
You can click on the BUY or RFQ button to purchase MCHVS1S07G from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MCHVS1S07G?
You can download the MCHVS1S07G datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MCHVS1S07G?
MULTICOMP PRO
