MULTICOMP PRO MCEI03 End Stackable DIP Switch
The MCEI-03 is a single-pole, single-throw end stackable DIP switch with three positions and through-hole terminals. It boasts gold-plated contacts, a gold-plated brass mechanism, and a UL94V-0 rated high-temperature thermoplastic base and cover. With a contact resistance of 100 milliohms at 500V DC, it ensures reliable switching performance. The switch offers insulation resistance of 100 megaohms and dielectric strength of 500VAC for one minute, making it ideal for industrial control, automation, and electronic systems requiring durable, high-quality switches.
MULTICOMP PRO MCEI03 End Stackable DIP Switch Specifications:
- Mechanical Life: 2,000 operations
- Max Operating Force: 1,000gf
- Stroke: 1mm
- Operating Temperature Range: -20°C to +85°C
- Storage Temperature Range: -40°C to +85°C
- Electrical Life: 2,000 cycles
- Rating: 25mA, 24V DC
- Contact Resistance: 100mΩ at 500V DC
- Insulation Resistance: 100Megaohms at 500V DC
- Dielectric Strength: 500V AC/1 minute
- Contact Arrangement: Single-pole, single-throw
- Base and Cover Material: UL 94V-0 Nylon high-temperature thermoplastic
- Actuator Color: Black
- Contact Material: Gold-plated alloy copper
- Terminal Material: Brass with gold plating
- Tape: Kapton
- Number of Positions: 3
- Number of Terminals: 3
Buy the Multicomp Dual In Line Switches – Reliable End Stackable for Industrial Applications
Purchase the end stackable DIP switch MCEI-03 online today for reliable performance in industrial automation and control projects. With gold-plated contacts and UL94V-0 thermoplastic base, it guarantees durability and safety. Ideal for control panels, automation systems, and electronic devices, this switch features a compact three-position design, high insulation resistance, and a dielectric strength of 500VAC for one minute. Secure your supply of high-quality switches easily through our online store and ensure seamless integration into your projects.
Order your multicomp series MCEI-03 end stackable DIP switch today and enhance your industrial control systems with dependable quality and high-performance switching.
