MULTICOMP PRO MCFE03009 Toroidal Transformer
This toroidal transformer offers reliable power conversion for various industrial and electronic applications. With a 30VA rating, it features dual secondary outputs of 9V and 15V, making it ideal for powering low-voltage equipment. Built with high-quality insulation and UL 1015 rated leads rated for 600V and 105°C, it ensures safety and durability in demanding environments. Its compact design measures 81.3mm in diameter and 39mm in height, weighing just 0.62kg. The transformer provides an efficiency of 86%, with low iron and copper losses, making it suitable for use in professional, industrial, and automation systems.
MULTICOMP PRO MCFE03009 Toroidal Transformer Specifications:
- Input Voltage: 230V 410% 50/60Hz
- DC Resistance: 87Ω 215% @ 20°C
- Magnetising Current: 4mA approx. @ 230V 50Hz
- Iron Loss: 0.39 Watts approx.
- Copper Loss: 4.3 Watts approx.
- Efficiency: 86% typical
- Temperature Rise: 34°C approx.
- Ambient Rated Temperature: 240°C
- Winding Wire: Class H (180°C)
- Insulation System: Class B (130°C)
- Leadout Insulation: Class A (105°C)
- Overall Insulation Class: Class A (105°C)
- Outer Diameter: 81.3mm
- Height: 39mm
- Weight: 0.62kg
- Lead Lengths: ~5mm, tinned ends, PVC sleeved primary leads rated for 600V / 105°C
- Terminals: All leads Tri-Rated UL1015 cable
- Rated Power: 30VA
- Secondary Voltage: 2 x 9V or 2 x 15V (depending on model)
- Termination: Double insulated primary leads, all leads tinned
- Certificate: RoHS Compliant
Buy the Brand MCFE03009 – Reliable Transformer for Industrial Applications
Purchase the toroidal transformer online today to ensure your electronic and industrial systems operate reliably. Featuring dual secondary outputs of 9V and 15V, high insulation standards, and UL 1015 rated leads, this compact and efficient transformer guarantees safety and durability. Its design includes low iron and copper losses, making it energy-efficient and suitable for professional and automation applications. Easy to install with robust cable termination, this 30VA transformer is your trusted choice for reliable power solutions, delivering consistent performance across diverse environments.
Buy Brand MCFE03009 now and experience unmatched reliability and performance in your power conversion needs.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MCFE03009?
You can click on the BUY or RFQ button to purchase MCFE03009 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MCFE03009?
You can download the MCFE03009 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MCFE03009?
MULTICOMP PRO
