MULTICOMP PRO MCSD75101KU 100uH SMD inductor with ferrite core
The multicomp series 100 microhenry SMD inductor with a ferrite core offers robust performance with a maximum DC resistance of 0.430 ohms and a current rating of 720mA. Designed for surface-mount technology, it features a compact external size of 5mm length, 7mm width, and 7mm depth, suitable for high-frequency applications with a resonant frequency of 100kHz. RoHS compliant, it operates within -55°C to +130°C, making it ideal for power filtering and RF circuits requiring reliable inductance with tight tolerance and thermal stability.
MULTICOMP PRO MCSD75101KU 100uH SMD inductor with ferrite core Specifications:
- Inductance: 100uH
- Inductance Tolerance: ±10%
- DC Resistance Max: 0.430Ω
- DC Current Rating: 720mA
- Inductor Case Style: SMD
- Number of Pins: 2
- Lead Spacing: 3mm
- Core Material: Ferrite
- External Depth: 7mm
- External Length/Height: 5mm
- External Width: 7.8mm
- Resonant Frequency: 100kHz
- Operating Temperature: -55°C to +130°C
- RoHS Compliant
- Material: Solder - Sn99.3%/Cu0.7%
- Wire: @0.25mm, 1P, 155°C
- Max DC Resistance: 430mΩ
- Inductor Series: MCSD75
- Lead Spacing: 3mm
Buy the Multicomp Series MCSD75 100uH SMD Inductor: MCSD75-101KU
Order the multicomp series 100uH SMD inductor online today and benefit from high-quality construction with a ferrite core, RoHS compliance, and a current rating of 720mA. Designed for surface-mount applications, this inductor offers a compact size of 5mm x 7mm x 7mm, making it ideal for high-frequency RF circuits, power filtering, and general electronic use. Its robust construction ensures operation across -55°C to +130°C with a resonant frequency of 100kHz, providing excellent stability and performance in demanding environments.
Buy Multicomp Series MCSD75 100uH SMD Inductor now and experience reliable high-frequency performance for your electronic applications.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MCSD75101KU?
You can click on the BUY or RFQ button to purchase MCSD75101KU from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MCSD75101KU?
You can download the MCSD75101KU datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MCSD75101KU?
MULTICOMP PRO
