MULTICOMP PRO MCFE05012 Toroidal Transformer
This toroidal transformer provides a reliable power solution for various electronic applications with a 50VA rating and dual secondary outputs of 12V each, suitable for industrial and DIY projects. It features a compact design with dimensions of 87.3mm outer diameter and 41.7mm height, made with high-quality insulating material, rated for 105°C insulation system, and compliant with RoHS standards. The transformer incorporates UL1015 style leadout wiring rated for 600V, ensuring safety and durability under various conditions. Its efficiency of approximately 89% makes it ideal for power supply and automation systems.
MULTICOMP PRO MCFE05012 Toroidal Transformer Specifications:
- Input Voltage: 230V ±10%, 50/60Hz
- Power Rating: 50VA
- Secondary Voltage: 2 x 12V
- Secondary Resistance: 2.08 Ohms
- Wire Gauge: 22AWG
- Lead Lengths: 150mm
- Outer Diameter: 87.3mm
- Height: 41.7mm
- Weight: 0.84kg
- Temperature Rating: 105°C insulation system
- Temperature Rise: 38°C approx.
- Ambient Temperature: 40°C
- Material: Copper wire, thermoplastics
- Insulation System: Class B, Class A, Class H
- Leadout Insulation: PVC sleeving rated 600V/105°C
- RoHS Compliant
Buy the Toroidal 50VA Transformer – Reliable Power for Industrial Applications
Enhance your electronic projects with this high-quality toroidal transformer, rated for 50VA with dual 12V secondary outputs. Designed with UL1015 rated leads, high insulation standards, and RoHS compliance, it offers durability and safety for industrial and DIY applications. Its compact size of 87.3mm diameter and 41.7mm height makes installation easier in tight spaces. Optimized for efficiency, it features approximately 89% efficiency with low losses, making it an ideal power source for automation, audio equipment, and power supplies. Order now for reliable performance!
Buy multicomp:ro toroidal transformer now and experience unmatched reliability, efficient power conversion, and robust insulation suited for industrial projects.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MCFE05012?
You can click on the BUY or RFQ button to purchase MCFE05012 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MCFE05012?
You can download the MCFE05012 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MCFE05012?
MULTICOMP PRO
