MULTICOMP PRO MCHVS1S09G Pin Header
This 1.27mm pin header with cap features a single row, vertical orientation, and SMD type construction suitable for various industrial and electronics assembly applications. It is rated for 1A current and 50V voltage, with gold-plated copper alloy contacts ensuring reliable electrical connections. The high-temperature plastic insulator provides durability up to +105°C. Designed for easy PCB mounting, it offers maximum contact resistance of 20mΩ, insulation resistance of 1000MΩ, and withstands 500V for one minute, making it ideal for compact, high-density electronic assemblies.
MULTICOMP PRO MCHVS1S09G Pin Header Specifications:
- Current Rating: 1A AC/DC
- Voltage Rating: 50V AC/DC
- Contact Resistance: 20mΩ Max.
- Insulation Resistance: 1000MΩ Min.
- Withstanding Voltage: 500V for one minute
- Operating Temperature Range: -25°C to +105°C
- Insulator Material: High-temp plastic (Nylon 9T UL94V-0)
- Contact Material: Copper Alloy, Gold Plated
- Color: Black
- Number of Positions: 9
- Height: 5.1mm
- Type: Single row, vertical, SMD
- Dimensions: Millimetres, suitable for compact PCB designs
Buy the Multicomp 1.27mm Pin Header – Reliable SMD Connectors for Industrial Applications
Purchase the high-quality Multicomp 1.27mm Pin Header with Cap online today and ensure your electronic assemblies are both reliable and efficient. This SMD connector features a single row, vertical design with gold-plated copper contacts for secure electrical connections. With a maximum current rating of 1A, voltage capacity of 50V, operating temperature from -25°C to +105°C, and a durable high-temp plastic insulator, it is perfect for compact, high-density electronic applications. Easy to install, RoHS compliant, and suitable for various industrial and consumer electronics projects.
Order your Multicomp 1.27mm Pin Header with Cap today and enhance your electronic projects with dependable, high-quality SMD connectors.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MCHVS1S09G?
You can click on the BUY or RFQ button to purchase MCHVS1S09G from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MCHVS1S09G?
You can download the MCHVS1S09G datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MCHVS1S09G?
MULTICOMP PRO
