MULTICOMP PRO MCKPSP2950PN16025A4763 Piezo Buzzer
The MCKPSP2950PN-16/0.25A-4763 is a reliable piezo buzzer designed for alarm and alert systems. It features a rated power of 0.25W and can handle up to 0.5W, ensuring clear sound output with a maximum distortion of 5%. With an impedance of 160 ±15% at 1,000 Hz and a resonant frequency of 600 Hz, it operates within a broad frequency range up to 7kHz. Compact with dimensions specified in millimeters and tested for durability under heat, cold, humidity, and load conditions, making it suitable for various industrial applications.
MULTICOMP PRO MCKPSP2950PN16025A4763 Piezo Buzzer Specifications:
- Impedance: 160 +15% at 1,000 Hz
- Resonant Frequency: 600 Hz 20%
- Frequency Range: FO - 7kHz
- Rated Power: 0.25W
- Maximum Power: 0.5W
- Sound Pressure Level: 89 +3dB 0.1W / 0.1Mat 1kHz
- Distortion Max: 5% at Rated Power 1kHz
- Sweep Test: Normal at Sine Wave 2V
- Load Test: Meets Item 8 Rated Noise Power, 24 hrs.
- Heat Test: Meets Item 8 50 +2°C 5 hrs.
- Cold Test: Meets Item 8 -20 +2°C 5 hrs.
- Humidity Test: Meets Item 8 40 +2°C, 90/95% RH 5 hrs.
- Polarity Test: Cone moves forward when supplied plus DC voltage
- Dimensions: Millimetres, Tolerance: +0.2mm
Buy the Multicomp Series Piezo Buzzer: MCKPSP2950PN-16/0.25A-4763
Order the Multicomp piezo buzzer MCKPSP2950PN-16/0.25A-4763 today and benefit from a compact, high-performance alert device suitable for alarm systems, instrumentation, and industrial use. With a rated power of 0.25W and a maximum power of 0.5W, it produces clear sound with a maximum distortion of 5%. Its durable construction withstands heat, cold, humidity, and load conditions, ensuring consistent performance in demanding environments. Purchase online now for fast delivery and easy integration into your projects.
Buy Multicomp piezo buzzer MCKPSP2950PN-16/0.25A-4763 now and enjoy reliable audio alerts with durable design for industrial applications.
