MULTICOMP PRO MCKSK6R3M471E11S Aluminium Capacitor
The multicomp Pro MCKSK series aluminium electrolytic capacitor offers high-temperature resistance up to 105°C, making it suitable for general electronic applications. It features a capacitance tolerance of +20% at 120Hz and 20°C, with operating temperature range from -40°C to +105°C. Rated voltages vary from 6.3V to 450V, ensuring versatile use across different circuits. The capacitor exhibits low leakage current, excellent stability, and minimal aging, suitable for power supplies, filtering, and decoupling in various electronic devices. Its robust design guarantees reliable long-term performance.
MULTICOMP PRO MCKSK6R3M471E11S Aluminium Capacitor Specifications:
- Capacitance Tolerance: +20% at 120Hz, 20°C
- Operating Temperature Range: -40°C to +105°C
- Rated Voltage Range: 6.3V to 450V
- Leakage Current: | = 0.01CV or 3uA after 2 min at Rated Voltage
- Dissipation Factor (tan δ): Max 0.24 at 120Hz, 20°C
- Impedance Ratio (Z at -25°C/Z at 20°C): Max 4 for 6.3V, Max 15 for 63V
- Load Life: 2000 hours at 105°C with stable capacitance change within +25%
- Shelf Life: Capacitance change within +20% of initial value over storage period
- Maximum Ripple Current: Varies with temperature, e.g., 1.85 at 60°C, 1.65 at 70°C, 1.4 at 85°C, 1.2 at 105°C
- Physical Dimensions: Length varies per capacitance, typically around 8-22 mm diameter, length up to 36 mm for larger capacities
Buy the Multicomp Series MCKSK Aluminium Electrolytic Capacitor: MCKSK6R3M471E11S
Purchase the multicomp Series MCKSK aluminium electrolytic capacitor online now for reliable performance in power supplies, filtering, and decoupling. This high-temperature capacitor is designed for long-term stability and excellent leakage current characteristics. Suitable for various voltage levels from 6.3V to 450V, it provides stable operation in demanding environments. Its robust construction ensures durability and consistent performance over time. Easily order online today and give your electronic projects the dependable quality they deserve with fast delivery and competitive prices.
Order your multicomp Series MCKSK6R3M471E11S aluminium electrolytic capacitor today and enhance your electronic projects with dependable quality.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MCKSK6R3M471E11S?
You can click on the BUY or RFQ button to purchase MCKSK6R3M471E11S from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MCKSK6R3M471E11S?
You can download the MCKSK6R3M471E11S datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MCKSK6R3M471E11S?
MULTICOMP PRO
