MULTICOMP-PRO MCL056AGW 5mm Multicomp LED
This 5mm multicomp LED offers vibrant orange and green colors, with a wide viewing angle of 145° and high luminous intensity. It features GaAsP on GaP/GaP dice material, rated for -40°C to +85°C operating temperatures and RoHS compliance. Suitable for indicator lights and illumination applications, it can handle forward currents up to 20mA, with a peak wavelength of 635/568nm. The LED is designed for easy soldering with a maximum lead temperature of 260°C for 5 seconds, ensuring reliable performance in various electronic projects.
MULTICOMP-PRO MCL056AGW 5mm Multicomp LED Specifications:
- Dice Material: GaAsP on GaP/GaP
- Emitted Colour: Orange / Green
- Lens Colour: White Diffused
- Peak Wavelength: 635/568nm
- Viewing Angle: 145°
- Luminous Intensity: 16/15mcd
- Reverse Voltage: 5V
- Reverse Current: 10μA
- Operating Temperature Range: -40°C to +85°C
- Storage Temperature Range: -40°C to +100°C
- Lead Soldering Temperature Range: 260°C for 5 seconds
- Forward Voltage: 1.6/1.7V (typical at 20mA)
- Maximum Forward Current: 100mA (peak, duty 1/10, 1kHz)
- Recommended Forward Current: 20mA
- Maximum Dimensions: 5mm diameter, length varies with model
Buy the Buy Multicomp LED Part Number MCL056AGW Online
Purchase the high-quality 5mm multicomp LED in vibrant orange and green colors online today. Designed for durability and precise illumination, this LED features a wide 145° viewing angle, low power consumption, and RoHS compliance. Perfect for indicators, lighting, and electronic projects, it supports a maximum forward current of 20mA, with peak wavelengths at 635 and 568nm for bright, consistent light output. Reliable soldering with a maximum of 260°C for 5 seconds ensures seamless integration into your designs. Order now for fast, secure delivery.
Get Multicomp LED MCL056AGW today—optimized for reliable indicator and illumination applications with long-lasting performance.
Frequently Asked Questions
Where can I buy MULTICOMP-PRO MCL056AGW?
You can click on the BUY or RFQ button to purchase MCL056AGW from an authorized MULTICOMP-PRO distributor.
How do I troubleshoot issues or seek technical support for part MCL056AGW?
You can download the MCL056AGW datasheet or visit the MULTICOMP-PRO website for support.
Who is the manufacturer of MCL056AGW?
MULTICOMP-PRO
