MULTICOMP PRO MCL236PURGW Bi-Colour LED
The multicomp pro Bi-Colour LED is a compact indicator light combining red and green emissions for clear visual signaling. Made from GaAlAs/GaP dice, it features a white diffused lens, peak wavelengths of 660nm for red and 568nm for green, and a viewing angle of 120°. It operates within -40°C to +85°C and can withstand soldering temperatures up to 260°C. Suitable for electronic and industrial applications, this bi-color LED provides high luminous intensity, low forward voltage, and reliable performance with RoHS compliance, making it an essential component for status indication and user interface designs.
MULTICOMP PRO MCL236PURGW Bi-Colour LED Specifications:
- Dice Material: GaAlAs/GaP
- Emitted Colour: Super Red/Green
- Lens Colour: White Diffused
- Peak Wavelength: 660/568nm
- Viewing Angle: 120°
- Luminous Intensity: 12/3.14 med
- Reverse Voltage: 5V
- Reverse Current: 10uA at Ve = 5V
- Operating Temperature Range: -40°C to +85°C
- Storage Temperature Range: -40°C to +100°C
- Lead Soldering Temperature Range: 260°C for 5 seconds at 2.4mm from body
- Forward Voltage: 1.5/1.7V min, 2.5/2.6V max at IF = 20mA
- Peak Forward Current: 100mA (duty cycle 1/10 at 1kHz)
- Recommended Operating Current: 20mA
- Spectral Line Half-Width: 20/30nm
Buy the Buy Multicomp Bi-Colour LED Part Number MCL236PURGW Online
Purchase the Multicomp Bi-Colour LED online today to enhance your electronic designs with vibrant red and green light signals. This 2mm by 5mm LED offers high luminous intensity, wide viewing angles, and robust operation within -40°C to +85°C temperatures. Ideal for indicator lights, displays, and signaling applications. Its RoHS compliance ensures environmentally safe usage. Enjoy fast, secure online buying with trusted retailers, quick delivery, and excellent customer support to meet your project needs efficiently.
Buy Multicomp Bi-Colour LED MCL236PURGW now and experience reliable performance, bright red and green indication, perfect for your electronic projects.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MCL236PURGW?
You can click on the BUY or RFQ button to purchase MCL236PURGW from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MCL236PURGW?
You can download the MCL236PURGW datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MCL236PURGW?
MULTICOMP PRO
