MULTICOMP PRO MCNDI04S DIP Switch
The MCNDI-04S is a single-pole single-throw low-profile DIP switch designed for easy machine insertion with gold-plated contacts and terminals. It features high reliability with double contacts, offeres insulation resistance of 100 MΩ at 500V, and dielectric strength of 500VAC for 1 minute. Suitable for vapor phase and IR-reflow soldering, it is used in industrial automation, process control, and communication networks. Its compact design with splay terminals facilitates high-volume automated PCB assembly and reliable switching operations in demanding environments.
MULTICOMP PRO MCNDI04S DIP Switch Specifications:
- Contact Arrangement: SPST
- Number of Poles: 4
- Contact Rating: 25mA, 24VDC
- Contact Resistance: 50mΩ Max.
- Insulation Resistance: 100MΩ Min. at 500V DC
- Dielectric Strength: 500VAC/1 minute
- Operating Temperature: -20°C to +85°C
- Storage Temperature: -40°C to +85°C
- Travel: > 1mm
- Operating Life: 2,000 cycles
- Terminal Type: Splay
- Dimensions: THT 11.14mm x 7.62mm
- Material: Gold-plated contacts and terminals
- RoHS Compliant
- RoHS: Yes
Buy the Multicomp Series MCNDI DIP Switch: MCNDI-04S
Order the Multicomp MCNDI-04S DIP switch online today to improve your electronic projects with reliable switching performance. Featuring gold-plated contacts for optimal conductivity, high insulation resistance of 100 MΩ, and dielectric strength of 500VAC, this low-profile, easy-to-insert switch is perfect for automation, process control, and communication networking. Its compact design, with splay terminals, supports automated PCB assembly and ensures excellent long-term durability even in demanding environments. Secure your supply and boost your design reliability today.
Buy Multicomp MCNDI-04S now and experience unmatched reliability and high-quality performance in industrial automation and control systems.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MCNDI04S?
You can click on the BUY or RFQ button to purchase MCNDI04S from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MCNDI04S?
You can download the MCNDI04S datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MCNDI04S?
MULTICOMP PRO
