MULTICOMP PRO MCPAS6B2M1CE7 Industrial Pushbutton Switch
The MCPAS6B2M1CE7 is a heavy-duty industrial pushbutton switch with a durable IP67 rated sealed enclosure, ideal for harsh environments. Designed with a flat plunger top for easy marking, it features solder lug terminals for reliable connections and an anti-rotation threaded bushing for secure mounting. With a contact resistance of 50 milliohms and insulation resistance of at least 1 gigaohm at 500V DC, it ensures precise performance. It supports operating forces between 2N to 5N, withstands 500,000 mechanical cycles, and is rated for a dielectric strength of 1000 VAC RMS, suitable for various automation and industrial control applications.
MULTICOMP PRO MCPAS6B2M1CE7 Industrial Pushbutton Switch Specifications:
- Max. Current/Voltage Rating with Resistive Load: 400mA 32V AC, 100mA 50V DC, 125mA 125V AC
- Max. Initial Contact Resistance: 50 milliohms
- Min. Insulation Resistance: 1 GΩ at 500V DC
- Dielectric Strength: 1000 VAC rms
- Electrical Life at Full Load: 500,000 cycles
- Panel Thickness: 0.8mm to 1.8mm
- Total Travel: 1.5mm (0.059")
- Operating Force: 2N to 5N
- Mechanical Life: 1,000,000 cycles
- Max. Torque: 1.5 Nm
- Soldering Temperature: 350°C for approximately 5 seconds
- Soldering Process: Manual, wave, vapor phase
- Switch Function: SPST Normally Open
- Pad Mounting: Snap-in or threaded bushing
- Ingress Protection: IP67
- Dimensions: Flat plunger diameter 12mm (0.472"), mounting hole diameter 6mm (0.236")
Buy the Multicomp Series Push Button Switch: MCPAS6B2M1CE7
Order the Multicomp industrial IP67 pushbutton switch MCPAS6B2M1CE7 online today. Designed for durability and sealed against dust and water ingress, it features a flat plunger for easy marking, solder lug terminals for secure wiring, and an anti-rotation threaded bushing for stable mounting. Suitable for automation, machinery, and control systems, this switch offers a contact resistance of 50 milliohms, insulation resistance of 1 gigaohm, dielectric strength of 1000 VAC RMS, and supports millions of cycles, ensuring long-lasting and dependable operation in demanding environments.
Get Multicomp push button switch MCPAS6B2M1CE7 today—built for industrial durability, reliable contact performance, and IP67 sealing for harsh environments.
