MULTICOMP PRO MCPAS6B2M1CES25L6 Industrial Illuminated Toggle Switch
The MCPAS6B2M1CES25L6 is a reliable industrial toggle switch featuring illumination options in various colors such as yellow, green, blue, and red. Specifically designed for panel mounting, it offers a compact and durable design with IP67 ingress protection, making it suitable for harsh environments. The switch supports resistive loads up to 200mA at 50V DC and 250V AC, with a mechanical life of 21 million cycles. Its electrical specifications include insulation resistance of 1GΩ minimum at 500V DC and dielectric strength of 1500V AC rms for metal material. Operating temperature ranges from -30°C to 85°C, with a total travel of 1.5mm and operating force of 2N to 5N. Soldering must be performed at 350°C for 5 seconds, ensuring safety and reliability in various industrial applications.
MULTICOMP PRO MCPAS6B2M1CES25L6 Industrial Illuminated Toggle Switch Specifications:
- Current / Voltage Rating: 200mA 50V DC, 250V AC rms, resistive load
- Initial Contact Resistance: 50mΩ max
- Insulation Resistance: 1GΩ minimum at 500V DC
- Dielectric Strength: 1500V AC rms for metal material
- Electrical Life: 21,000,000 cycles
- Operating Temperature: -30°C to 85°C
- Panel Thickness: 0.8mm min. - 1.8mm max. (B1 series), 1.5mm min. - 4mm max. (B2 series)
- Total Travel: 1.5mm
- Operating Force: 2N to 5N
- Soldering Temperature: 350°C for 5 seconds
- Ingress Protection: IP67, protected against immersion up to 1 meter for 30 minutes
- Switch Function: Momentary, Single Pole, Single Throw
- Physical Dimensions: Panel mount diameter approximately 20mm, height varies with model
- Mechanical Life: 21 million cycles
- Operating Force: 2N-5N
- Switch Type: Illuminated toggle with LED indicators
- Schematic: SP, MOM (Momentary) operation
- Housing Material: Durable plastic with metal options available
- Color Options: White, Red, Green, Blue, Yellow, Super Red, Super Green, Super Blue
- Operating Temperature Range: -30°C to 85°C
Buy the multicomp MCPAS6B2M1CES25L6 – Reliable Industrial Illuminated Switch for Industrial Applications
Discover the high-performance multicomp MCPAS6B2M1CES25L6 illuminated toggle switch, designed for harsh industrial settings. Featuring IP67 protection, it is ideal for applications requiring durable, reliable switching in demanding environments. With a maximum resistive load of 200mA at 50V DC and 250V AC, it ensures high electrical performance and longevity. Its compact panel-mount design supports various panel thicknesses, with a total travel of 1.5mm and operating force between 2N and 5N. Soldering at 350°C for 5 seconds guarantees secure and safe installation, making it the perfect choice for industrial automation, control panels, and machinery.
Buy multicomp MCPAS6B2M1CES25L6 now and experience unmatched reliability and long life in rugged industrial environments.
