MULTICOMP PRO MCPAS6D1M1CES35 Illuminated Control Switch
The MCPA series switches are compact, panel-mounting electrical components designed for diverse applications. They feature illuminated LED indicators with various color options, robust construction with IP 67 protection against immersion up to 1 meter for 30 minutes, and built-in electro-optical data suitable for reliable signaling. These switches support manual and wave soldering processes, with durable mechanical and electrical life cycles, making them ideal for industrial automation, control panels, and machinery interfaces. Available in round and square configurations, they combine high performance with easy installation, ensuring dependable operation in demanding environments.
MULTICOMP PRO MCPAS6D1M1CES35 Illuminated Control Switch Specifications:
- Current / Voltage Rating: 400mA 32V AC, 100mA 50V DC, 125mA 125V AC, 500mA 48V AC, 200mA 50V DC, 250V AC
- Initial Contact Resistance: 50mQ max.
- Insulation Resistance: 1GO min. at 500V DC
- Dielectric Strength: 1,000V AC rms, 1,500V AC rms for metal material
- Electrical Life: 500,000 cycles
- Operating Temperature: -30°C to 85°C
- Panel Thickness: B1 series 0.8 mm min. -1.8 mm max., B2 series 1.5 mm min. -4 mm max.
- Total Travel: B1 series 1.8 mm, B2 series 4 mm
- Operating Force: 2N to 5N
- Switch Function: No, Positive, Momentary (varies by model)
- Soldering: Manual at 350°C for 5 sec., wave at 260°C ±5°C for max 5 sec.
- Ingress Protection: IP67 protection against water immersion up to 1 meter for 30 minutes
- Electrical and optical specifications include various LED colors with forward voltage (VF) of 1.7–3.6V typical, LED current up to 250mA, wave angle of 470–660°, and peak viewing wave length of 460–630 nm.
Buy the Buy multicomp Illuminated Control Switch Part Number MCPAS6D1M1CES35 Online
Enhance your control panels with the high-quality multicomp illuminated control switch. Featuring IP67 waterproof protection, multiple LED color options, and support for manual and wave soldering, this switch offers outstanding durability and reliable performance in demanding industrial environments. Its compact, panel-mount design simplifies installation while providing excellent electrical life over 500,000 cycles. Whether used in automation systems, machinery interfaces, or control applications, order this versatile switch online today to ensure your project’s dependability and hassle-free setup.
Order your multicomp Series MCPAS6D1M1CES35 illuminated control switch today and ensure reliable operation with high durability and IP67 protection.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MCPAS6D1M1CES35?
You can click on the BUY or RFQ button to purchase MCPAS6D1M1CES35 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MCPAS6D1M1CES35?
You can download the MCPAS6D1M1CES35 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MCPAS6D1M1CES35?
MULTICOMP PRO
