MULTICOMP-PRO MCR13447A101HR Toggle Switch
This non-illuminated toggle switch features a round lever actuator, 2P SPST on-off configuration, and panel mounting with quick connect terminals. Constructed with nylon 6.6 and copper alloy contacts, it offers reliable performance up to 16A at 250V AC, with a waterproof and dustproof design suitable for industrial environments. The switch has a dielectric strength of 1500V AC, insulation resistance of 100MΩ, and contact resistance below 50mΩ. Operating within -20°C to +85°C, it’s ideal for applications demanding durability and safe switching. Its compact dimensions ensure easy integration into control panels and machinery.
MULTICOMP-PRO MCR13447A101HR Toggle Switch Specifications:
- Switch Function: 2P, SPST, On-Off
- Mounting: Panel
- Terminal: Quick Connect
- Actuator Type: Round Lever
- Ratings: 16A (4A) /250V AC
- Contact Resistance: 50mΩ Max
- Insulation Resistance: 100MQ Min @ 500V DC
- Dielectric Strength: 1500V AC for 1 minute
- Operating Temperature: -20°C to +85°C
- Material Frame: Nylon 6.6, Black
- Material Actuator: Nylon 6.6 + 30% GF
- Material Terminal: Copper Alloy
- Material Contact: Copper Alloy
- Waterproof & Dustproof: IP56
- Dimensions: Refer to diagram, mounting hole 3.4mm, tolerances 0.3mm
Buy the Multicomp Non-Illuminated Toggle Switch – Reliable Control for Industrial Applications
Purchase the high-quality non-illuminated toggle switch online today to ensure durable, reliable control in your industrial projects. Featuring a round lever, panel mounting, and waterproof IP56 rating, this switch is perfect for demanding environments. Designed with nylon and copper alloy components, it provides excellent electrical performance up to 16A at 250V AC, with dielectric strength of 1500V. Its compact size and quick connect terminals make installation straightforward, helping you achieve safe, reliable operation in control panels and machinery.
Buy Multicomp non-illuminated toggle switch now and experience dependable switching performance with waterproof protection for industrial environments.
