MULTICOMP PRO MCTB61C04 Eurostyle Terminal Block
The MCTB-61C04 is a 4-position Eurostyle terminal block with a 5mm pitch, designed for wire-to-board connections. Featuring a right-angle, through-hole layout, it accommodates wire sizes from 22 to 14 AWG and operates safely at voltages up to 300V AC with a current rating of 16A. Made from polyamide 66, it boasts a brass, tin-plated terminal, a nickel-plated brass cage clamp, and an M3 zinc-plated steel screw, ensuring durability and reliability in industrial environments. It functions within a temperature range of -40°C to 105°C, ideal for complex wiring systems.
MULTICOMP PRO MCTB61C04 Eurostyle Terminal Block Specifications:
- Rated Voltage: 300V AC
- Rated Current: 16A
- Wire Size: 22 to 14 AWG
- Housing Material: Polyamide 66
- Cage Clamp Material: Brass, Ni plated
- Terminal Material: Brass, tin plated
- Screw Size: M3, steel, zinc plated
- Operating Temperature: -40°C to +105°C
- Dimensions: 12 positions, length 10 mm to 60 mm (varies by model), pitch 5mm
- PCB hole diameter: 1.3mm
- Torque: 24.5 Ib-inch
Buy the Buy Eurostyle Terminal Block Part Number MCTB-61C04 Online
Order the Eurostyle Terminal Block MCTB-61C04 online for your industrial wiring needs. Its 5mm pitch, rated for 300V AC and 16A, features durable brass and polyamide construction, ideal for robust electrical systems. The right-angle through-hole design and screw connections ensure secure wiring. With operating temperatures from -40°C to 105°C, it is suitable for a wide range of industrial applications. Quick online purchase guarantees a high-quality, reliable component, backed by warranty and trusted by professionals worldwide for precision and durability.
Get Eurostyle Terminal Block MCTB-61C04 today—designed for reliable industrial wiring and long-lasting performance.
