MULTICOMP-PRO MCTF0805ATY2002 Thin Film Resistor
The MCTF series thin film NiCr passivated resistor offers a wide resistance range with very tight tolerances from ±0.01% to 1%, ensuring high-precision performance in various applications. Manufactured by Multicomp Pro, a trusted brand rated 4.6 out of 5 stars, this resistor is suitable for medical equipment, measurement systems, printers, and communication devices. It features a ceramic alumina substrate, Ag and NiCr electrodes, and epoxy overcoating for durability. Compact 0805 size, low TCR, and high stability make it ideal for demanding environments and precision circuits.
MULTICOMP-PRO MCTF0805ATY2002 Thin Film Resistor Specifications:
- Resistance Range: 4.7Ω to 1MQ
- Tolerance: ±0.01% to 1%
- Temperature Coefficient of Resistance (TCR): +5PPM/°C
- Power Rating at 70°C: 1/10W
- Maximum Operating Voltage: 100V
- Overload Voltage: 200V
- Operating Temperature Range: -55°C to +155°C
- Dimensions: 0.15 inch (3.81 mm) length, width 0.15 inch (3.81 mm), thickness 0.055 inch (1.39 mm)
- Construction: Alumina substrate with Ag bottom electrode, Ag-Pd top electrode, NiCr edge electrode, Ni barrier layer, Sn external electrode, NiCr resistor layer, epoxy overcoat
- Features: Very tight tolerance, low TCR, RoHS compliant, suitable for precision electronic circuits
- Additional: Compact size, high stability, wide resistance range, suitable for automated and high-reliability environments
Buy the Multicomp Series 0805 Thin Film Resistor: MCTF0805ATY2002
Purchase the high-precision Thin Film Resistor from Multicomp Pro online today. With a resistance range from 4.7Ω to 1MQ, tight tolerance up to ±0.01%, and excellent stability, this compact 0805 resistor is ideal for medical, measurement, and communication devices. Its durable ceramic alumina substrate, Ag and NiCr electrodes, and epoxy overcoat ensure reliable performance in demanding environments. Buy online now for quick delivery and ensure your circuits meet the highest standards of accuracy and reliability.
Get Multicomp Series 0805 Thin Film Resistor today—built for precision and long-lasting durability.
Frequently Asked Questions
Where can I buy MULTICOMP-PRO MCTF0805ATY2002?
You can click on the BUY or RFQ button to purchase MCTF0805ATY2002 from an authorized MULTICOMP-PRO distributor.
How do I troubleshoot issues or seek technical support for part MCTF0805ATY2002?
You can download the MCTF0805ATY2002 datasheet or visit the MULTICOMP-PRO website for support.
Who is the manufacturer of MCTF0805ATY2002?
MULTICOMP-PRO
