MULTICOMP PRO MCTF0805BTC2001 Precision Chip Resistor
The MCTF series thin film NiCr passivated resistor offers a wide resistance value range with very tight tolerances from ±0.01% to 1%. These high-quality resistors are part of the Multicomp Pro product line, rated 4.6 out of 5 stars, and come with a 12-month limited warranty. They are designed for precision applications requiring reliable performance, including medical equipment, testing and measurement devices, printers, automatic controllers, and communication devices such as cell phones, GPS, and PDAs. Constructed on alumina substrates with Ag and NiCr electrodes, these resistors feature dimensions suitable for high-precision electronic circuits.
MULTICOMP PRO MCTF0805BTC2001 Precision Chip Resistor Specifications:
- Resistance Range: 4.70 to 1MQ
- Tolerance: ±0.01%, ±0.05%, ±0.1%, ±0.25%, ±0.5%, ±1%
- Temperature Coefficient of Resistance (TCR): ±5PPM/°C or specified
- Power Rating at 70°C: 1/10W
- Max Operating Voltage: 100V
- Max Overload Voltage: 200V
- Dimensions: Length 2.4 mm, Width 1.25 mm, Thickness 0.15 mm
- Construction: Alumina substrate with Ag bottom electrode, Ag-Pd top electrode, NiCr edge and resistor layer
- Environmental Resistance: Endurance >7,000 hours at rated power, MIL-STD-202 compliant
- Temperature Range: -55°C to +155°C
- Insulation Resistance: >1,000 MΩ
- Soldering Conditions: Reflow soldering with maximum temperature 260°C, 3 reflow cycles allowed
- Marking: 'Z 4992' with 'EA' indication
Buy the Multicomp Series 0805 Precision Resistor: MCTF0805BTC2001
Enhance your electronic projects with the Multicomp precision chip resistor, MCTF0805BTC2001. Offering ultra-tight tolerance from ±0.01% to 1% and a resistance range up to 1 megaohm, these resistors are ideal for high-accuracy measurement and control systems. Designed with high-quality materials on alumina substrates, they ensure reliability and temperature stability. Perfect for applications in medical, communication, testing, and automation industries, order online today to benefit from fast delivery, exceptional performance, and lasting durability for your electronic assemblies.
Get Multicomp series 0805 precision resistor MCTF0805BTC2001 today—built for precision and long-lasting durability.
