MULTICOMP PRO MCTG101M1EB0813P Aluminum Electrolytic Capacitor
The MCTG101M1EB-0813P is an axial aluminum electrolytic capacitor with tinned copper wire leads, encased in a PVC sleeve. It operates efficiently over a temperature range of -40°C to +105°C, making it suitable for high-temperature applications. Rated for voltages from 6.3V to 100V DC and with a capacitance of 100uF, it complies with JIS C5141 standards, ensuring quality and durability. Its compact dimensions, with a diameter of 8mm and length of 13mm, make it ideal for space-constrained electronic circuits requiring reliable, long-lasting components.
MULTICOMP PRO MCTG101M1EB0813P Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 100uF
- Working Voltage: 6.3V to 100V DC
- Temperature Range: -40°C to +105°C
- Dimensions: Diameter 8mm, Length 13mm
- Leakage Current: ≤ 0.02CV or 3uA (whichever is greater) after 2 minutes at rated voltage
- Dissipation Factor (Tan δ): 0.23 at 6.3V, 0.2 at 10V, 0.17 at 16V, 0.15 at 25V, 0.12 at 35V
- Impedance at 120Hz: Z(+20°C) up to 18Ω for 6.3V, decreasing with higher voltages
- Surge Voltage: 7.3V to 125V depending on rated voltage
- Shelf Life: Meets load life characteristics after 1000 hours at 85°C with applied voltage
- Material: Aluminum casing with PVC sleeve, tinned copper leads
- Standards: Meets W characteristics of JIS C5141
Buy the Buy Multicomp Aluminum Electrolytic Capacitor Part Number MCTG101M1EB0813P Online
Experience the unmatched quality and durability of the Multicomp aluminum electrolytic capacitor. This high-performance component features a rated voltage between 6.3V and 100V DC, operating reliably from -40°C to +105°C. Its compact size of 8mm diameter and 13mm length makes it ideal for space-sensitive circuits. Suitable for power supply filtering, signal coupling, and buffering, this capacitor guarantees long-lasting stability, low leakage current, and high-quality construction, all essential for demanding electronic projects and industrial applications.
Buy Multicomp aluminum electrolytic capacitor MCTG101M1EB-0813P now and ensure reliable performance in your high-temperature electronic applications.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MCTG101M1EB0813P?
You can click on the BUY or RFQ button to purchase MCTG101M1EB0813P from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MCTG101M1EB0813P?
You can download the MCTG101M1EB0813P datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MCTG101M1EB0813P?
MULTICOMP PRO
