MULTICOMP-PRO MCTR100JDD1501 Power Resistor
The power resistor MCTR100JDD1501 is a high-performance, RoHS-compliant 100-watt power resistor designed for applications like gate resistors, snubbers, and voltage regulation. It features a molded, electrically isolated case for protection and easy mounting, with a heat sink-compatible TO-247 style package. Capable of operating from -65°C to +175°C, it has a resistance range from 0.050Ω to 100kΩ with a TCR between -100 and +200 PPM/°C, making it ideal for demanding power electronics and high-frequency environments, ensuring durability and reliability.
MULTICOMP-PRO MCTR100JDD1501 Power Resistor Specifications:
- Power Rating: 100 watts at 25°C case temperature
- Resistance Range: 0.050Ω to 100kΩ
- TCR: -100 to +200 PPM/°C depending on type
- Operating Voltage: Max 700V
- Dielectric Strength: 1,800V AC
- Insulation Resistance: 10GΩ min.
- Operating Temperature Range: -65°C to +175°C
- Case Material: Molded, RoHS compliant
- Lead Material: Tinned Copper
- Mounting: Single M3 screw to heat sink
- Dimensions: Typical case width 0.147 inches (3.73mm), case length varies according to model
- Environmental Tests: Load Life 2000 hours, Moisture Resistance, Thermal Shock, Vibration
- Construction: Alumina substrate, resistor layer, molded case
Buy the Buy multicomp Power Resistors Part Number MCTR100JDD1501 Online
Order the multicomp power resistor MCTR100JDD1501 online today to experience durable, high-wattage performance. Perfect for power supplies, RF, and voltage regulation, this RoHS-compliant resistor features a molded case for protection, excellent heat dissipation, and a wide operating temperature range from -65°C to +175°C. Its robust construction and high power rating make it ideal for demanding high-frequency and industrial applications. Purchase now to ensure reliable and efficient power management in your electronic projects and industrial systems.
Buy multicomp MCTR100JDD1501 now for high-power, reliable performance in power supplies, snubbers, and voltage regulation applications.
Frequently Asked Questions
Where can I buy MULTICOMP-PRO MCTR100JDD1501?
You can click on the BUY or RFQ button to purchase MCTR100JDD1501 from an authorized MULTICOMP-PRO distributor.
How do I troubleshoot issues or seek technical support for part MCTR100JDD1501?
You can download the MCTR100JDD1501 datasheet or visit the MULTICOMP-PRO website for support.
Who is the manufacturer of MCTR100JDD1501?
MULTICOMP-PRO
