MULTICOMP PRO MCUMR16V476M63X5 High-density Electronic Capacitor
This 5mm, 85°C multicomp:ro capacitor features a compact design suitable for high-density electronic applications such as compact office machines, mini-audio sets, and digital devices. It has a rated voltage of 25V, capacitance of 47uF with +20% tolerance, and operates within a temperature range of -40°C to +85°C. The capacitor demonstrates excellent stability, low leakage current, and withstands circuit-board cleaning, making it ideal for modern electronic equipment with tight space requirements. Its robust construction ensures reliable long-term performance in demanding environments.
MULTICOMP PRO MCUMR16V476M63X5 High-density Electronic Capacitor Specifications:
- Operating temperature range: -40°C to +85°C
- Rated voltage: 25V DC
- Capacitance: 47μF with +20% tolerance
- Leakage current: | = 0.01 CV or 3 μA after two minutes
- Dissipation factor (tan delta): maximum 0.12 at 120 Hz/ +20°C
- Size: 6.3mm diameter x 5mm length
- High temperature stability after 1,000 hours at +85°C
- Shelf life: withstands 500 hours at +85°C without voltage
- UL and RoHS compliant
- Suitable for circuit-board cleaning with ultrasonic or steam cleaning
Buy the Multicomp Series MCUMR 47uF Capacitor 25V: MCUMR16V476M63X5
Purchase the Multicomp Series MCUMR 47uF capacitor online today—engineered for high-density circuits, offering stable performance at -40°C to +85°C, with 25V operating voltage. Its compact size makes it ideal for space-constrained electronic devices, including portable gadgets, office automation equipment, and audio systems. With excellent temperature stability, low leakage, and RoHS compliance, this capacitor ensures long-lasting durability and reliable operation in demanding environments. Improve your circuit design—order online now for fast delivery.
Get Multicomp Series MCUMR 47uF capacitor today—compact design, reliable performance for high-density electronic applications.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MCUMR16V476M63X5?
You can click on the BUY or RFQ button to purchase MCUMR16V476M63X5 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MCUMR16V476M63X5?
You can download the MCUMR16V476M63X5 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MCUMR16V476M63X5?
MULTICOMP PRO
